Up to 5X Faster with Dual-Radio 3x3 11AC MIMO Technology
The UniFi AC Pro AP supports simultaneous dual-band, 3x3 MIMO technology in the 5 and 2.4 GHz radio bands.

Designed for Optimal RF Performance
The newly redesigned UniFi Controller optimizes RF performance:

Versatile Design
The UniFi AC Pro AP is a gigabit, 802.3af-powered access point suitable for indoor or outdoor use.

Scalable Enterprise Wi-Fi Management
The UniFi Controller v5 software is a powerful, enterprise wireless software engine ideal for high-density client deployments requiring low latency and high uptime performance. With its software-based capabilities, the UniFi virtual control plane allows for unlimited scalability under one centralized controller. Remotely access the UniFi Controller to upgrade deployed UniFi APs while in the field.

UAP-AC-PRO
Deploy the UniFi AC Pro AP indoors or outdoors, in
wireless networks requiring maximum performance.
Sporting a weatherproof design, the UniFi AC Pro AP
features simultaneous, dual-band, 3x3 MIMO technology
and convenient 802.3af PoE/802.3at PoE+ compatibility.
It is available in single- and five‑packs

Dimensions
196.7 x 196.7 x 35 mm (7.74 x 7.74 x 1.38")

Weight
With Mounting Kits
350 g (12.4 oz)
450 g (15.9 oz)

Networking Interface
(2) 10/100/1000 Ethernet Ports

Port
(1) USB 2.0 Port

Buttons
Reset

Power Method
Passive Power over Ethernet (48V), 802.3af/802.3at Supported
(Supported Voltage Range: 44 to 57VDC)

Power Supply
UniFi Switch (PoE)

Power Save
Supported

Maximum Power Consumption
9W

Maximum TX Power
2.4 GHz - 22 dBm
5 GHz - 22 dBm

Antennas
(3) Dual-Band Antennas, 2.4 GHz: 3 dBi, 5 GHz: 3 dBi

Wi-Fi Standards
802.11 a/b/g/n/r/k/v/ac

Wireless Security
WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)

BSSID Up to 8 per Radio
Mounting Wall/Ceiling (Kits Included)

VLAN
802.1Q

Advanced
QoS Per-User Rate Limiting

Guest Traffic Isolation Supported
WMM Voice, Video, Best Effort, and Background
Concurrent Clients 250+
