Omni-directional 802.11ac Wave 2 Wi-Fi Access Point with 4x4 MU-MIMO technology. The price / performance leader in enterprise Wi-Fi.
The UniFi nanoHD is a compact 4x4 MU-MIMO 802.11ac Wave 2 dual-band access point with an aggregate radio rate of over 2 Gbps and supports over 200 concurrent users. Engineered to take advantage of 802.11ac Wave 2, the UniFi nanoHDprovides powerful multi-user support in an elegant, nano-sized design.

Features:

Four-Stream 802.11ac Wave 2 Technology
Simultaneous Dual-Band Radios
Supports 200+ Concurrent Users
5 GHz Band 4x4 Multi-User MIMO with Radio Rate of 1.733 Gbps
2.4 GHz Band 2x2 MIMO with Radio Rate of 300 Mbps
Powered by Gigabit 802.3af PoE+
*PoE injector included only with single pack

Dimensions - 160 x 160 x 32.65 mm (6.3 x 6.3 x 1.29")

Weight - 300 g (10.6 oz)
Networking Interface - (1) RJ45 GbE
Buttons - (1) Reset to Defaults
Power Method - 802.3af
Power Supply - UniFi Switch (PoE)
Max. Power Consumption - 10.5W
Operating Frequency - 2.4 GHz / 5 GHz

Max. TX Power
2.4 GHz - 23 dBm
5 GHz - 26 dBm

Antenna Gain
2.4 GHz - 2.8dBi
5 GHz - 3dBi

MIMO
2.4 GHz - 2x2
5 GHz - 4x4

Throughput
2.4GHz - 300 Mbps
5GHz - 1733 Mbps

Wi-Fi Standards - 802.11 a/b/g/n/ac/ac-wave2
Wireless Security - WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
BSSID - 8 per Radio
Mounting - Wall/Ceiling (Kits Included)
Operating Temperature - -10 to 70° C (14 to 158° F)
Operating Humidity - 5 to 95% Noncondensing
