All-in-one console and security gateway designed to support powerful LAN and WiFi networks.

Features:
Dual-band WiFi 5 access point
Four-port Gigabit switch
Advanced network security (content filtering, internet threat management, deep packet inspection)
Pre-installed UniFi Network application

Powered by a fast 1.7 GHz quad‑core processor, the UDM combines multiple functions into a single elegant device.

Integrated 4x4 Enterprise AP
The UDM delivers the requisite high‐performance Wi‐Fi and fits into high‐density environments as part of the overall enterprise network.

Integrated Security Gateway
The UDM offers advanced firewall policies and persistent threat management to act as an Intrusion Prevention System (IPS) and Intrusion Detection System (IDS).

Integrated Cloud Key
The UniFi Network Application can provision UniFi devices, map out networks, and quickly manage system traffic.

Integrated Gigabit Switch
The UDM provides a managed 4-port Gigabit switch so you can easily add network storage or wired client devices.

HIGH‐PERFORMANCE ANTENNA
802.11ac Wave 2 4x4 MU-MIMO for 5 GHz and 802.11n for 2.4 GHz

PROCESSOR
ARM Cortex-A57 Quad-Core at 1.7 GHz

ADVANCED SECURITY
Gateway with IPS and DPI

ETHERNET PORTS
5 GbE Ports: 1 WAN and 4 LAN

VLAN SUPPORT
Security and Traffic Management

SECURE COMMUNICATIONS
VPN Server

QOS
Enterprise VoIP

UniFi Application with Intuitive User Interface
Centralized management software featuring a graphical user interface offers easy setup and convenient control.
