Redefining WiFi Routers
With powerful WiFi 7 performance, lightning-fast wired connections, and a brand-new design.

Blazing-Fast 9.2 Gbps Tri-Band WiFi 7
Enables your devices to run at full speed. Enjoy fluent 4K/8K streaming, immersive AR/VR gaming, and blazing-fast downloads.

Multi-Link Operation (MLO)
Increases throughput, reduces latency, and improves reliability for emerging applications

Full 2.5G Ports
One 2.5 Gbps WAN port and four 2.5 Gbps LAN ports break through the 1G bottleneck, driving your devices to peak performance.

Maximized Coverage
Proprietary WiFi optimization and optimally positioned antennas along with Beamforming deliver more capacity, stronger and more reliable connections, and less interference.

EasyMesh-Compatible
Works with EasyMesh routers and range extenders to form seamless whole home Mesh WiFi, preventing drops and lag when moving between signals.

TP-Link HomeShield
Enhanced security defends against the latest cyber threats.

WiFi 7 — WiFi Like Never Before
WiFi 7 offers accelerated throughput, lower latency, stronger anti-jamming, and higher efficiency. Join the league of pros and experience the sheer performance of the next generation of WiFi.

320 MHz
Doubles the width, doubles the speed

4K-QAM
Packs 20% more data than WiFi 6 for higher speeds

Multi-Link Operation
Increases throughput, reduces latency, and improves reliability

Multi-RUs
Makes full use of every resource for maximum efficiency

Ultra-Fast 9214 Mbps 6-Stream Tri-Band WiFi
Enjoy smooth 8K streaming, VR/AR, video conferencing, online gaming, and high-speed downloading.

5× 2.5 Gbps Ports for Full Multi-Gigabit Connectivity
One 2.5 Gbps WAN port maximizes home internet speeds with up to 2.5× the wired speed of a typical Gigabit Ethernet port. The additional four 2.5 Gbps LAN ports make Archer BE550 an ideal solution for future-proofing your home network.☆ Let’s begin the unprecedented smooth game!

6× Internal Antennas with Beamforming, for Broader Coverage
Proprietary WiFi optimization and 6× optimally positioned antennas boost WiFi signals throughout your home.

Beamforming Technology
Detects devices and concentrates signals towards them, especially to previously hard-to-reach areas.

Flexibly Create Whole Home Mesh WiFi
Archer BE550 is EasyMesh-compatible. If you have any dead zones at home, just add another EasyMesh router/range extender to further form your whole home multi-gigabit mesh WiFi. No more searching for a stable connection.

Easy Setup and Use
Whether you prefer the intuitive Tether app or TP-Link’s powerful web interface, you can set up your Archer BE550 in minutes. The Tether app allows you to manage network settings from any Android or iOS device.

VPN Clients and Server Supported
Allow devices in your home network to access remote VPN servers without needing to install VPN software on every device. Archer BE550 can run both the VPN and ordinary internet connections at the same time, delivering security and flexibility.

Private IoT Network for More Security
Set up a separate WiFi for IoT devices and overlay HomeShield and advanced WPA3 encryption to better protect the security of your home network and IoT devices.

WIRELESS
WiFi Speeds: BE9300
• 6 GHz: 5760 Mbps (802.11be)
• 5 GHz: 2880 Mbps (802.11be)
• 2.4 GHz: 574 Mbps (802.11ax)

WiFi Range: 4 Bedroom Houses
6× Optimally Positioned Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas

Beamforming
Concentrates wireless signal strength towards clients to expand WiFi range

High-Power FEM
Improves transmission power to strengthen signal coverage

WiFi Capacity: High

Tri-Band
Allocate devices to different bands for optimal performance

2×2 MU-MIMO
Simultaneously communicates with multiple MU-MIMO clients

OFDMA
Simultaneously communicates with multiple clients

Airtime Fairness
Improves network efficiency by limiting excessive occupation

DFS
Access an extra band to reduce congestion

6 Streams
Connect your devices to more bandwidth

Working Modes:
• Router Mode
• Access Point Mode

Advanced Features:
• Multi-Link Operation (MLO)
• 320 MHz Channel
• 4K-QAM
• Multi-RUs
• EasyMesh-Compatible
• Works with Alexa and Google Assistant
• IoT Network

SECURITY
Network Security
• SPI Firewall
• Access Control
• IP & MAC Binding
• Application Layer Gateway

• HomeShield Security
Real-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanner

Guest Network:
• 1× 6 GHz Guest Network
• 1× 5 GHz Guest Network
• 1× 2.4 GHz Guest Network

VPN Server:
• OpenVPN Server
• PPTP VPN Server
• L2TP VPN Server

VPN Client:
• Open VPN Client
• PPTP VPN Client
• L2TP VPN Client

WiFi Encryption:
• WPA
• WPA2
• WPA3
• WPA/WPA2-Enterprise (802.1x)

HARDWARE
Processor: High-Performance CPU
Ethernet Ports:
• 1× 2.5 Gbps WAN
• 4× 2.5 Gbps LAN

USB Support: 1× USB 3.0

• Supported Partition Formats:
NTFS, exFAT, HFS+, FAT32

• Supported Functions:
FTP Server
Media Server
Samba Server

Buttons:
• Power On/Off Button
• Wi-Fi On/Off Button
• LED Button
• WPS Button
• Reset Button

Power: 12 V ⎓ 3.3 A

SOFTWARE
Protocols:
• IPv4
• IPv6

Service Kit: HomeShield
EasyMesh: Compatible with EasyMesh

Parental Controls:
HomeShield Parental Controls
Custom Profiles
Professional Content Filter Library
Family Time
Bedtime
Off Time
Time Rewards
Family Online Time Ranking
Pause the Internet
Weekly and Monthly Reports

WAN Type:
• Dynamic IP
• Static IP
• PPPoE
• PPTP
• L2TP

Quality of Service: QoS by Device

Cloud Service:
• Auto Firmware Upgrade
• TP-Link ID
• DDNS

NAT Forwarding:
• Port Forwarding
• Port Triggering
• DMZ
• UPnP

IPTV:
• IGMP Proxy
• IGMP Snooping
• Bridge
• Tag VLAN

DHCP:
• Address Reservation
• DHCP Client List
• Server

DDNS:
• TP-Link
• NO-IP
• DynDNS

Management Features:
• Tether App
• Webpage

OTHER
Network Services Enabled by Default

Web Server
Manage and configure device through web (HTTP/HTTPS): • Port: 80/443   Protocol: TCP

DNS
DNS: • Port: 53   Protocol: TCP & UDP

DHCP Server:
IP address assignment (DHCP)
• Port: 67   Protocol: UDP

App management:
Manage and configure device through app
• Port: 20001   Protocol: TCP
• Port: 30001   Protocol: TCP
• Port: 20002   Protocol: UDP

System Requirements: Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser

Cable or DSL Modem (if needed)

Subscription with an internet service provider (for internet access)

Environment:
• Operating Temperature: 0℃~40℃ (32℉ ~104℉)
• Operating Humidity: 10%~90% non-condensing

PHYSICAL
Dimensions (W×D×H): 3.0 × 9.1 × 8.0 in (76 × 231.7 × 203 mm)
