AX6600 Tri-Band WiFi: Boosts overall speeds up to an incredible 6600 Mbps

AI-Driven Mesh: Intelligently learns the network environment to provide ideal Wi-Fi unique to your home

Smart Antennas: Establish a stronger backhaul to boost coverage and improve wireless connections

Connect More Devices: Connect up to 200 devices without dragging down performance

Boosted Seamless Coverage: Achieve seamless whole home coverage with a clearer and stronger whole home Wi-Fi signal generated by Wi-Fi 6

TP-Link HomeShield: Keeps your home network safe with cutting-edge features for network and IoT protection

Setup Made Easier Than Ever: The Deco app walks you through setup step-by-step

Easy Management
Manage your Wi-Fi at home or away on the Deco app, including seeing all connected devices, prioritizing your own, setting up a guest network, and more.

Voice Control
Pair with Alexa to control Deco X20 with simple voice commands. Enjoy the convenient life.

All Decos Work Together
Deco X20 is compatible with every other Deco model to form a mesh network. Expand mesh Wi-Fi coverage anytime by simply adding more Decos.

WIRELESS
Standards - Wi-Fi 6
IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11ax/n/b/g 2.4 GHz

WiFi Speeds - AX6600
5 GHz: 4804 Mbps (802.11ax, HE160)
5 GHz: 1201 Mbps (802.11ax)
2.4 GHz: 574 Mbps (802.11ax)

WiFi Capacity - Very High
Tri-Band
Distribute devices to different bands for optimal performance

4×4 MU-MIMO
Simultaneously communicates with multiple MU-MIMO clients

OFDMA
Simultaneously communicates with multiple WiFi 6 clients

8 Streams
More than enough bandwidth for connected devices
Working Modes - Router Mode
Access Point Mode

HARDWARE
Processor - 1.5 GHz Quad-Core CPU
Ethernet Ports - 1× 2.5 Gbps Port
1× Gigabit Port
Supports WAN/LAN auto-sensing
Buttons - Reset Button

SECURITY
WiFi Encryption - WPA-Personal
WPA2-Personal
WPA3-Personal
Network Security - SPI Firewall
Access Control

HomeShield Security
Real-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanner
Guest Network - 1× 5 GHz Guest Network
1× 2.4 GHz Guest Network
SOFTWARE
Protocols - IPv4
IPv6

Parental Controls - HomeShield Parental Controls
Custom Profiles
Professional Content Filter Library
Family Time
Bedtime
Off Time
Time Rewards
Family Online Time Ranking
Pause the Internet
Weekly and Monthly Reports

WAN Types -
Dynamic IP
Static IP
PPPoE
PPTP
L2TP

Quality of Service -
HomeShield QoS
QoS by Device

Cloud Service -
OTA Firmware Upgrade
TP-Link ID
DDNS

NAT Forwarding -
Port Forwarding
UPnP
IPTV - IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN

DHCP -
Address Reservation
DHCP Client List
Server

DDNS - TP-Link
Management - Deco App

PHYSICAL
Dimensions (W×D×H) - 5.1 × 4.8 × 8.3 in
(130 × 123 × 210 mm)
