Up to 3.0 Gbps Dual Band Wi-Fi
Separates 5 GHz (2402 Mbps) and 2.4 GHz (574 Mbps) WiFi bands for faster speeds and greater capacity with the WiFi 6 technology.

Smart Roaming
Walk from room to room and stay connected with the fastest possible speeds.

EasyMesh-Compatible
Flexibly creates a Mesh network by connecting to an EasyMesh-compatible router for seamless whole-home coverage.

AP Mode
Create a new WiFi access point through the Gigabit Ethernet port to enhance your wired network with WiFi capability.

Adaptive Path Selection
Automatically choosing the fastest connection path to the router.

Easy Setup
Plug in and then easily set up via a press of the WPS button or via the Tether App.

Ultimate Compatibility
Extends the range of any Wi-Fi router or wireless access point

Life in the fast lane with advanced WiFi6
WiFi 6 comes with it all: faster speeds, lower latency, and more connections. It also features 25% faster data throughput compared with last-gen WiFi thanks to 1024-QAM.‡ With this speed boost, experience high-speed and stable WiFi throughout your rooms.

Double Channel Speed with HE160
Higher Efficiency, Lower Latency
Supports 2x2 160MHz on the 5G band, enjoys wider bandwidth and faster speed than the traditional 80MHz

4 high-performance amplifiers, we got you covered
Enjoy 4K streaming and gaming in whatever room you’re in thanks to RE715X’s 4 high-performance amplifiers. Whether you’re sharing a pad with friends or living in your forever home, RE715X sends out strong signals to those hard-to-cover areas.

OFDMA
More efficient data.
Orthogonal Frequency Division Multiple Access helps integrate the data of different end devices for higher efficiency

Beamforming
Strong, targeted WiFi.
Find the direction of your phone or laptop, and accelerate your signal strength.

Adaptive Path Selection
Keeps your network running at top speed by automatically choosing the fastest connection path to the router.

WiFi Dead Zone Killer
Eliminate weak signal areas with WiFi coverage for the whole house

Smart Roaming
Uninterrupted streaming when moving around your home§

One WiFi Name
No more switching WiFi network names

Built-In Access Point Mode
RE715X is more than a wireless range extender. Simply plug an Ethernet cable into its Ethernet port, and easily turn your wired internet connection into a 2×2 MU-MIMO dual band wireless access point.

Control at Your Fingertips
Set up and manage your WiFi through the TP-Link Tether app from your phone (Android, iOS), including TP-Link routers and range extenders.

HARDWARE FEATURES
Interface: 1 Gigabit Ethernet Port
Button:
• WPS Button
• Reset Button

Input Power: 100-240V~50/60Hz
Max. Power Consumption: 15.2W
Dimensions ( W x D x H ): 107×40×160 mm
Antenna 2 External Antennas

WIRELESS FEATURES
Wireless Standards
• IEEE 802.11a/n/ac/ax 5GHz
• IEEE 802.11b/g/n/ax 2.4GHz
Frequency: 2.4GHz and 5GHz
Signal Rate:
• 574 Mbps at 2.4GHz
• 2402 Mbps at 5GHz

Working Modes: Range Extender / Access Point
Reception Sensitivity:
5GHz:
11a 6Mbps:-97dBm
11a 54Mbps:-78dBm
11ax HE20 MCS0: -97dBm
11ax HE20 MCS11: -66dBm
11ax HE40 MCS0: -94dBm
11ax HE40 MCS11: -62dBm
11ax HE80 MCS0: -92dBm
11ax HE80 MCS11: -61.5dBm
11ax HE160 MCS11: -59dBm

2.4GHz:
11g 6Mbps:-96dBm
11g 54Mbps:-78dBm
11ax HE20 MCS0: -95dBm
11ax HE20 MCS11: -66dBm
11ax HE40 MCS0: -93.5dBm
11ax HE40 MCS11: -62dBm

Wireless Functions
• Enable/Disable Wireless Radio
• DFS (the latest firmware and hardware version is required)
• Access Control
• LED Control
• Power Schedule
• Wi-Fi Coverage Adjustment

Wireless Security
• WEP
• WPA
• WPA2
• WPA3

Transmission Power
• 2.4 GHz ≤ 16 dBm
• 5 GHz ≤ 21 dBm

Mesh Technology EasyMesh-Compatible

OTHER
Network Services Enabled by Default: Web Server
Manage and configure device through web (HTTP/HTTPS)
• Port: 80/443 Protocol: TCP

DHCP Server
IP address assignment (DHCP)
• Port: 67 Protocol: UDP

App management
Manage and configure device through app
• Port: 20001   Protocol: TCP
• Port: 20002   Protocol: UDP

OTHERS
Package Content
• Wi-Fi Range Extender RE715X
• Quick Installation Guide

System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
