Next-Gen Gigabit Wi-Fi 6 Speed
2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz band ensure smoother streaming and faster downloads.

Connect More Devices
OFDMA technology increases capacity by 4 times to enable simultaneous transmission to more devices.

Ultra-Low Latency
Enables more responsive gaming and video chatting.

Expanded Wi-Fi Coverage
Four high-gain external antennas and Beamforming technology combine to extend strong, reliable Wi-Fi throughout your home.

TP-Link HomeShield
Enhanced security defends against the latest cyber threats.

Improved Battery Life
Target Wake Time helps your devices to communicate more while consuming less power.

Compatible with Alexa
Control your router via voice commands and make your life smarter and easier with Amazon Alexa.

WIRELESS
Standards - Wi-Fi 6
IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11ax/n/b/g 2.4 GHz

WiFi Speeds - AX3000
5 GHz: 2402 Mbps (802.11ax, HE160)
2.4 GHz: 574 Mbps (802.11ax)

WiFi Range - 3 Bedroom Houses
4× Fixed High-Performance Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas

Beamforming
Concentrates wireless signal strength towards clients to expand WiFi range

High-Power FEM
Improves transmission power to strengthen signal coverage

WiFi Capacity - High
Dual-Band
Allocate devices to different bands for optimal performance

OFDMA
Simultaneously communicates with multiple Wi-Fi 6 clients

Airtime Fairness
Improves network efficiency by limiting excessive occupation

DFS
Access an extra band to reduce congestion

4 Streams
Connect your devices to more bandwidth

Working Modes -
Router Mode
Access Point Mode

HARDWARE
Processor - High Performance CPU
Ethernet Ports -
1× Gigabit WAN Port
4× Gigabit LAN Ports

USB Support - 1× USB 3.0 Port

Supported Partition Formats:
NTFS, exFAT, HFS+, FAT32

Supported Functions:
Apple Time Machine
FTP Server
Media Server
Samba Server

Buttons -
Wi-Fi/WPS Button
Power On/Off Button
LED On/Off Button
Reset Button

Power - 12 V ⎓ 2 A

SECURITY
WiFi Encryption -
WPA
WPA2
WPA3
WPA/WPA2-Enterprise (802.1x)

Network Security -
SPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway

HomeShield Security
Real-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanner

Guest Network -
1× 5 GHz Guest Network
1× 2.4 GHz Guest Network

VPN Server -
OpenVPN
PPTP

SOFTWARE
Protocols -
IPv4
IPv6

Service Kits -
HomeShield

OneMesh™ - OneMesh™ Supported

Parental Controls -
HomeShield Parental Controls
Custom Profiles
Professional Content Filter Library
Family Time
Bedtime
Off Time
Time Rewards
Family Online Time Ranking
Pause the Internet
Weekly and Monthly Reports

WAN Types -
Dynamic IP
Static IP
PPPoE
PPTP
L2TP

Quality of Service - QoS by Device

Cloud Service -
Auto Firmware Upgrade
OTA Firmware Upgrade
TP-Link ID
DDNS

NAT Forwarding -
Virtual Servers
Port Forwarding
Port Triggering
DMZ
UPnP

IPTV -
IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN

DHCP -
Address Reservation
DHCP Client List
Server

DDNS -
TP-Link
NO-IP
DynDNS

Management -
Tether App
Webpage

PHYSICAL
Dimensions (W×D×H) -
10.2 × 5.3 × 1.5 in
(260.2 x 135.0 x 38.6 mm)
