Super-Fast 1.8 Gbps Wi-Fi
Enjoy smooth 4K streaming and downloading with super-fast Wi-Fi speeds of 1.8 Gbps.

Connect More Devices
Communicates with more devices using OFDMA while simultaneously reducing lag.

Broader Coverage
Improved algorithm, beamforming, and high-performance antennas enhance the Wi-Fi coverage performance.

Next-Gen Platform
The Next-Gen High-Efficiency Qualcomm Chipset provides fast and stable Wi-Fi while saving power consumption.

Parental Controls
Enjoy the most versatile yet free parental controls features among all routers, including URL blocking, profile management, pausing, and more.

Works with Most ISPs
Compatible with most ISPs with extra L2TP/PPTP support. IPTV support works with your existing TV over the Internet contract.

OneMesh
Use with OneMesh extenders to get whole-home coverage and enjoy smooth roaming between signals.

Easy Setup
Set up your router in minutes with the powerful TP-Link Tether App.

Backward Compatible
Supports all previous 802.11 standards Wi-Fi devices.

WIRELESS
Standards - Wi-Fi 6
IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11ax/n/b/g 2.4 GHz

WiFi Speeds - AX1800
5 GHz: 1201 Mbps (802.11ax)
2.4 GHz: 574 Mbps (802.11ax)

WiFi Range - 3 Bedroom Houses
4× Fixed High-Performance Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas

Beamforming
Concentrates wireless signal strength towards clients to expand WiFi range

WiFi Capacity - High
Dual-Band
Allocate devices to different bands for optimal performance

OFDMA
Simultaneously communicates with multiple Wi-Fi 6 clients

Airtime Fairness
Improves network efficiency by limiting excessive occupation

4 Streams
Connect your devices to more bandwidth

Working Modes -
Router Mode
Access Point Mode

HARDWARE
Processor - Dual-Core CPU
Ethernet Ports -
1× Gigabit WAN Port
4× Gigabit LAN Ports

Buttons -
WPS/Wi-Fi Button
Power On/Off Button
LED On/Off Button
Reset Button

Power - 12 V ⎓ 1 A

SECURITY
WiFi Encryption -
WPA
WPA2
WPA3
WPA/WPA2-Enterprise (802.1x)

Network Security -
SPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway

Guest Network -
1× 5 GHz Guest Network
1× 2.4 GHz Guest Network

VPN Server -
OpenVPN
PPTP
SOFTWARE

Protocols -
IPv4
IPv6

OneMesh™ -
OneMesh™ Supported

Parental Controls -
URL Filtering
Time Controls

WAN Types -
Dynamic IP
Static IP
PPPoE
PPTP
L2TP

Quality of Service - QoS by Device

Cloud Service -
Auto Firmware Upgrade
OTA Firmware Upgrade
TP-Link ID
DDNS

NAT Forwarding -
Port Forwarding
Port Triggering
DMZ
UPnP

IPTV -
IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN

DHCP -
Address Reservation
DHCP Client List
Server

DDNS -
TP-Link
NO-IP
DynDNS

Management -
Tether App
Webpage

PHYSICAL
Dimensions (W×D×H) -
10.2 × 5.3 ×1.5 in
(260.2 × 135.0 × 38.6 mm)
