Extend WiFi Coverage: Eliminate WiFi dead zones by expanding high-performance WiFi using specially designed high-gain antennas.
Wi-Fi 6 Speeds: Enjoy smoother and more reliable streaming, gaming, downloading, and more with dual-band WiFi speeds up to 1.5 Gbps.
Connect More Devices to Your Network: Connect more devices that are out of range from your main router while eliminating poor performance.
Gigabit Ethernet Port: Experience wired speed and reliability anywhere in your home with the gigabit ethernet port.
OneMeshTM Technology: Create a mesh network using compatible routers, like Archer A7, and range extenders so you never switch networks or lose signal.
Set Up in Minutes: Easily set up and manage your WiFi in a few quick and easy steps using the intelligent signal indicator and TP-Link Tether app (Android, iOS).
Universal Compatibility: Compatible with all WiFi-enabled devices and routers or access points. It even supports new AX phones, laptops and other devices

Cutting-Edge Wi-Fi 6
The latest WiFi technology eliminates annoying lag, endless loading, and dead spots. Enjoy the future of faster network connections

Fill Every Inch of Your Home with Wi-Fi 6
The RE505X wirelessly connects to your router, boosting your Wi-Fi 6 signal throughout your home so you can binge-watch your favorite show anywhere.

Adaptive Path Selection
Keeps your network running at top-speed by automatically choosing the fastest connection path to the router.

High-Speed Mode
Use both WiFi bands to enjoy super-fast connections —ideal for HD streaming and gaming.

Built-In Access Point Mode
RE505X is more than just a wireless range extender.
Simply plug an Ethernet cable into its port to easily turn that wired connection into a high-speed dual-band wireless signal.

TP-Link OneMesh TM
OneMeshTM is a simple way to form a Mesh network with a single WiFi name for seamless whole-home coverage. Just connect an OneMeshTM range extender to an OneMeshTM router so you can stop searching around for a stable connection.

Smart Roaming
Uninterrupted streaming when moving around your home

One WiFi Name
No more switching WiFi network names

Easy Creation
OneMeshTM Router and OneMeshTM Range Extenders pair instantly

Unified Management
Manage the entire network all from the TP-Link Tether app

Control at Your Fingertips
Set up and manage your WiFi through the TP-Link Tether app from your smartphone (Android, iOS), including TP-Link routers and range extenders.

HARDWARE FEATURES
Ports - 1 Gigabit Ethernet Port
Button - WPS Button, Reset Button
Power Consumption - 10W
Dimensions ( W x D x H ) - 2.9×1.8×4.9 in. (74.0×46×124.8 mm)
Antenna 2 External Antennas

WIRELESS FEATURES
Wireless Standards - IEEE 802.11a/n/ac/ax 5GHz, IEEE 802.11b/g/n 2.4GHz
Frequency - 2.4GHz and 5GHz
Signal Rate - 300 Mbps at 2.4GHz, 1200 Mbps at 5GHz

Reception Sensitivity 5GHz:

11a 6Mbps: -93dBm,
11a 54Mbps: -75dBm
11ac HT20 MCS0: -92dBm,
11ac HT20 MCS8: -70dBm
11ac HT40 MCS0: -90dBm,
11ac HT40 MCS9: -66dBm
11ac HT80 MCS0: -87dBm,
11ac HT80 MCS9: -62dBm

2.4GHz:

11g 54Mbps: -77dBm,
11n HT20 MCS7: -75dBm
11n HT40 MCS7: -72dBm

Transmit Power CE: 2.4GHz ≤20dBm, 5GHz ≤30dBm
Wireless Functions - Enable/Disable Wireless Radio, Wireless Statistics
Wireless Security - 64/128-bit WEP, WPA/WPA-PSK2 encryptions
