AC1200 Wireless MU-MIMO VDSL/ADSL Modem Router
Speedy WiFi – Experience superb wireless connections with 867 Mbps (5 GHz) + 300 Mbps (2.4 GHz) dual band WiFi
Superior Range – Two fixed omnidirectional antennas with Beamforming technology provide stable wireless connections and optimal coverage
Versatile Connectivity – Fully compatible with VDSL2/ADSL2+/ADSL2/ADSL standards, as well as fiber, cable, and 3G/4G internet services
Whole-Home Coverage with OneMeshTM – Works alongside TP-Link OneMeshTM products to create a flexible Mesh network
MU-MIMO Technology – Simultaneously transfers data to multiple devices, reducing wait times
Full Gigabit Ports – Take full advantage of broadband speeds up to 1 Gbps
Tether App– TP-Link Tether provides the easiest way to access and manage your router on your iOS and Android devices

A Modem for All
Your Networking Needs
AC1200 Wireless MU-MIMO VDSL/ADSL Modem Router
Archer VR400

Superfast WiFi Up to 1.2 Gbps
Archer VR400 unlocks the full potential of your internet connection by providing combined dual-band WiFi speeds of up to 1.2 Gbps, including 867 Mbps on the 5 GHz band and 300 Mbps on the 2.4 GHz band, eliminating lag and buffering from your online activities.
Two dedicated WiFi networks support more devices and reduce wireless interference to create stable connections.

High-Speed
VDSL Modem Router
Advanced VDSL2 technology allows Archer VR400 to deliver impressive VDSL broadband speeds of up to 100 Mbps—nearly 4× faster than ADSL2+. Archer VR400 serves as a DSL modem and wireless router, combining two devices in one.
*The integrated DSL port supports all standard DSL connections, including VDSL2, ADSL2+, ADSL2, and ADSL.

Versatile Backup Connectivity
With multiple ports, Archer VR400 provides you with a variety of options when connecting to the internet. As a backup, the LAN/WAN port allows Archer VR400 to accept connections from cable and fibre modems via an Ethernet cable. Additionally, the USB port supports 3G/4G dongle connections.

Flexible Create a Whole Home WiFi
OneMesh™ is a simple way to form a Mesh network with a single WiFi name for seamless whole-home coverage. Just connect an OneMeshTM range extender to an OneMesh™ router. No more searching around for a stable connection.

Wi-Fi Dead-Zone Killer
Eliminate weak signal areas with Wi-Fi coverage for the whole house

Smart
Roaming
Uninterrupted streaming when moving around your home

One Wi-Fi
Name
No more switching Wi-Fi network names

Unified Management
Manage the whole-home Wi-Fi by managing the central node via Tether app/Web UI

Superior Range and Stability
Two high-performance external antennas help Archer VR400 create an expansive home network. Advanced Beamforming technology automatically locates wireless devices and forms targeted, highly efficient wireless connections.

MU-MIMO for Higher Efficiency
MU-MIMO technology serves multiple devices at once, reducing wait time, increasing WiFi throughput for every device, and making each stream more efficient

Blazing Fast Wired Performance
To help your wired devices achieve peak performance, the router’s Gigabit Ethernet ports operate 10× faster than standard Ethernet. Full Gigabit ports provide rapid, reliable wired connections to computers, TVs, and game consoles.

Easy Setup and Use
Set up Archer VR400 in minutes thanks to its intuitive web interface and the powerful Tether app. Tether also lets you manage the router’s network settings from any Android or iOS device, including parental controls and guest network.

Interface
3× 10/100/1000Mbps RJ45 LAN Ports,
1× 10/100/1000Mbps RJ45 WAN/LAN Port,
1× RJ11 Port,
1× USB 2.0 Port

Button
WPS Button, Wi-Fi On/Off Button, Reset Button

External Power Supply
12V/1A

IEEE Standards
IEEE 802.3, IEEE 802.3u, 802.3ab

VDSL2 Standards
ITU G.993.2, Up to 17a profile (POTS)
ITU-T G.993.5 (G.vector)
ITU-T G.998.4 (G.INP)

ADSL Standards
Full-rate ANSI T1.413 Issue 2,
ITU-T G.992.1(G.DMT),
ITU-T G.992.2(G.Lite),
ITU-T G.994.1 (G.hs),

ADSL2 Standards
ITU-T G.992.3 (G.DMT.bis)

ADSL2+ Standards
ITU-T G.992.5

Dimensions ( W x D x H )
8.5 × 4.9 × 1.2 in (215.6 × 124.6 × 31.6 mm)

Antenna Type
2× fixed Omini-Directional antennas

WIRELESS FEATURES
Wireless Standards
IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz

Frequency
2.4 GHz and 5 GHz

Signal Rate
867Mbps at 5 GHz, 300Mbps at 2.4 GHz

Wireless Functions
Enable/Disable Wireless Radio, WMM, Wireless Statistics

Wireless Security
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions

Transmission Power
<20dBm (2.4 GHz), <23dBm (5 GHz)

Wireless Schedule
Support 2.4 GHz and 5 GHz Wireless Schedule

SOFTWARE FEATURES
Security
NAT Firewall, SPI Firewall, Access Control, Service Filtering, Denial of Service (DoS), SYN Flooding, Ping of Death, IP and MAC Address Binding

Operating Modes
VDSL/ADSL Modem Router, Wireless Router, 3G/4G Router

Management
Web-Based Configuration (HTTP / HTTPS ), Remote management,
Command Line Interface, SSL for TR-069, SNMP v1/2c, Firmware Upgrade, Diagnostic Tools, Free Online Firmware Update

DHCP
Server, Client, DHCP Client List, Address Reservation, DHCP Relay
Port Forwarding Virtual Server, Port Triggering, DMZ, ALG, UPnP

Dynamic DNS
DynDns, NO-IP, TP-Link

VPN
OpenVPN, PPTP VPN, IPSec VPN

Protocols
Supports IPv4 and IPv6

ATM/PPP Protocols
ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC 1483 Routed), Bridge (RFC1483 Bridge), PVC – Up to 8 PVCs

Advanced Features
Parental Controls, Network Address Translation(NAT), Port Mapping
(Grouping), Static Routing, RIP v1/v2 (optional), DDNS, IGMP V1/V2/V3

Guest Network
2.4GHz Guest Network, 5GHz Guest Network
