5 10/100/1000Mbps RJ45 ports
With four PoE ports, transfers data and power on one single cable
Working with IEEE 802.3af compliant PDs, expands home and office network
802.1p/DSCP QoS enable smooth latency-sensitive traffic
Supports PoE Power up to 15.4W for each PoE port
Supports PoE Power up to 56W for all PoE ports
Requires no configuration and installation

Interface -
• 5× 10/100/1000Mbps RJ45 Ports
• AUTO Negotiation
• AUTO MDI/MDIX

Network Media -
• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
• EIA/TIA-568 100Ω STP (maximum 100m)
• 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
• EIA/TIA-568 100Ω STP (maximum 100m)
• 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
• EIA/TIA-568 100Ω STP (maximum 100m)

Fan Quantity - Fanless
External Power Supply - External Power Adapter (Output: 53.5 VDC / 1.31 A)
Packet Forwarding Rate - 7.44 Mpps
PoE Ports (RJ45) -
• Standard: 802.3 af/at compliant
• PoE Ports: Ports 1–4
• Power Supply: 65 W

Mac Address Table - 2K
Jumbo Frame - 16 KB
Switching Capacity - 10 Gbps
Dimensions ( W x D x H ) - 3.9×3.9×1.0 in (99.8×98×25 mm)

Max Power Consumption -
• 4.29 W (220/50 Hz. no PD connected)
• 74.24 W (220/50 Hz. with 65 W PD connected)

Max Heat Dissipation -
• 14.63 BTU/h (no PD connected)
• 253.16 BTU/h (with 65 W PD connected)

SOFTWARE FEATURES
Advanced Features -
• Compatible With IEEE 802.3af/at Compliant PDs
• Mac Address Auto-Learning And Auto-Aging
• IEEE 802.3x Flow Control
• 802.1p/DSCP QoS
• IGMP Snooping

Transfer Method - Store-And-Forward
