Wireless N Speed & Range
Adopting IEEE 802.11n advanced MIMO (Multi Input Multi Output) technology, it simultaneously works through three antennas with smart antenna technology to Tx and Rx to overcome the interference and signal degradation when traveling long distances or through physical barriers in a small office or a large apartment, resulting in an incredible improvement in the wireless performance, even in a steel-and-concrete building.

Multiple Operating Modes
- Easy to Build WLAN
Supports AP Client, Bridge, Repeater and AP operation modes to enable various wireless applications to give users a more dynamic and comprehensive experience when using your AP. Multiple operating mode also helps you easily build wireless network for hard-to-wire locations or eliminating wireless dead zone.

Passive PoE Supported
-More Flexible Deployment
The TL-WA901ND is able to be powered using an Ethernet cable to simultaneously send data and electricity to wherever your AP may be located even up to 100 feet away. This feature multiplies your options allowing you to place the AP in a position that is most convenient to get the best signal possible, such as on the wall or on the ceiling of your office.

HARDWARE FEATURES
Interface - One 10/100M Ethernet Port(RJ45)
Support - Passive PoE
Button - WPS/Reset, Power On/Off
Power Consumption - 5.8W
External Power Supply - 12VDC/1A
Wireless Standards - IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Dimensions ( W x D x H ) - 7.67*5.12*1.43 in.( 194.82*129.93*36.2mm)
Antenna Type - 3*5dBi Detachable Omni Directional (RP-SMA)

WIRELESS FEATURES
Frequency - 2.4-2.4835GHz
Signal Rate -
11n: Up to 450Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)

Transmit Power - <20dBm(EIRP)
Wireless Modes - Access Point /Repeater (Range Extender)/ Bridge with AP/ Client/Multi-SSID/
Wireless Functions - Enable/Disable Wireless Radio;
WMM (Wi-Fi Multimedia)
Wireless MAC Address Filtering
Wireless Statistic
Domain Login Function

Wireless Security - 64/128/152-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK
DHCP - DHCP Server
Quality of Service - WMM
Management - SNMP
Advanced Functions - Up to 30 meters PoE is supported
