Smart Wi-Fi all around
Multiple MR2200ac can work together as a system to bring Wi-Fi to every corner of your home. Wherever you go, stay on a single Wi-Fi network and enjoy seamless connectivity from one place to another.

The intelligence behind your mesh network
The algorithms built into SRM make deployment incredibly easy. The system intelligently self-configures, self-optimizes, and even self-heals, always giving you the fastest possible path to the Internet.

Security at the perimeter
It's not just people that you need to protect. It's all the connected things: IP cameras, smart doorbells, alarm systems… things that can make a smart home vulnerable. MR2200ac installs multiple layers of protection to shield your network against cyberattacks happening every day.

Advanced functionality made accessible
For small offices who don't want the hassle of wiring access points everywhere, a mesh Wi-Fi solution fits in perfectly. Unlike others, MR2200ac doesn't leave out the network management features businesses care about.

CPU
Quad core 717 MHz

Memory
256 MB DDR3

Antenna Type
2x2 MIMO high-performance internal antenna (2.4 GHz / 5 GHz)

LAN Port
Gigabit (RJ-45) x 1

WAN Port
Gigabit (RJ-45) x 1

External Ports
USB 3.0 x 1 (5V, 0.9A power output)
USB 3.2 Gen 1 x 1 (5V, 0.9A power output)
IEEE 802.11ac
IEEE 802.11a/b/g/n/ac

Simultaneous tri-band Wi-Fi
5GHz-1: 867Mbps
5GHz-2: 867Mbps
2.4GHz: 400Mbps
IEEE 802.11ac Wave 2
MU-MIMO

Wi-Fi Encryption
WEP, WPA/WPA2-Personal, WPA/WPA2-Enterprise, WPA2/WPA3-Personal, WPA3-Personal/Enterprise, Wi-Fi Enhanced Open (OWE)

Button and Switch
WPS, Power, Reset, Wi-Fi On/Off

Size (Height x Width x Depth)
154 mm x 199 mm x 65 mm

Weight
0.45 kg

AC Input Power Voltage
100 V to 240 V AC

Power Frequency
50/60 Hz, Single Phase

Power Consumption
12.95 W (Access)
5.21 W (Idle)
