ROTATABLE BLOCKHEAD
Mount the cold plate at any orientation, turn the blockhead up to 270 degrees, and keep it upright.

RADIATOR PUMP DESIGN
The pump has been integrated into the radiator for sound dampening and noise reduction. Additionally, placing the pump into the radiator also increases the pump's life expectancy by moving it away from the heat source.

PUMP MOTOR RESONANCE ELIMINATION
A durable three phase motor at the core of the pump generates minimal vibrations for long-lasting operation.

HIGH THERMAL DISSIPATION
A split pathway through the radiator rapidly dissipates heat, cooled liquid is then pumped back into the loop.

MYSTIC LIGHT COMPATIBLE
Show off your colors with full ARGB customization on the fans and cooling block.

EVAPORATION PROOF TUBING
Constructed with three layers of netted plastic tubing and a reinforced mesh exterior.

DIY 2.0 – INTEGRATING WITH THE SYSTEM ENVIRONMENT
Connect and synchronize with MSI coolers and cases with strategically positioned pin-header locations including a dedicated pump-fan header.

MORE SILENCE THAN EXPECTED
MAG CORELIQUID 360R V2's noise level is significantly lower than that of competitor's by 10%.

COOLING YOU CAN'T HEAR
For those who prefer a quieter environment, a bundled noise reducer cable changes the fans’ speed to produce less sound while still providing good airflow.

RADIATOR DIMENSIONS (WXDXH) - 394 x 120 x 27mm / 15.5 x 4.7 x 1.06 inches
RADIATOR MATERIAL - Aluminum
NUMBER OF FANS - 3
FAN DIMENSIONS (WXDXH) - 120 x 120 x 25mm / 4.7 x 4.7 x 0.98 inches
FAN SPEED - 500 ~ 2000 RPM
FAN AIR FLOW - 21.63 ~ 78.73 CFM
FAN NOISE LEVEL - 14.3 ~ 34.3 dBA
FAN BEARING - Two Ball Bearing
FAN RATED CURRENT - 0.15 A
FAN POWER CONSUMPTION - 1.8 W
PWM MODE - Yes
CABLE LENGTH (PWM CABLE) - 550 / 350mm; 21.65 / 13.78 inches
FAN LIGHTING - ARGB
PUMP POWER CONSUMPTION - 4.08W
PUMP SPEED - 4200 ±10%RPM
BLOCK DIMENSIONS (WXDXH) - 80.57x 66.82 x 48.58mm / 3.17 x 2.63 x 1.91 inches

INTEL SOCKET SUPPORT - LGA 1150/1151/1155/1156/1200/1700
LGA 1366/2011/2011-3/2066

AMD SOCKET SUPPORT - AM5/AM4/FM2+/FM2/FM1/AM3+/AM3/AM2+/AM2
SocketTR4/sTRX4/SP3
