Quality of Service (QoS)
Numerous QoS features ensure that traffic is prioritized properly to deliver the best possible user experience for real-time applications like voice and video along with bandwidth-intensive graphic/video file uploads and downloads. IGMP snooping limits IP multicast traffic to the ports that requested it, enabling the rest of the network to operate at peak efficiency.

Network Security
Unauthorized access to the network and mission-critical data is a constant concern. Linksys smart switches help secure networks through port authentication and MAC-based port security, requiring clients to authenticate themselves before any data is passed. Advanced DHCP snooping and IP-MAC binding functions ensure network integrity and help prevent network attacks.

Network Expansion
Linksys smart switches include features for quickly expanding and growing your network. Multiple high-bandwidth trunks between switches enhance availability and redundancy. Spanning Tree Protocol (STP) and Storm Control features help control planned or inadvertent cable loops.

Interfaces
Inputs/Outputs -
24 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45)
2 x 10/100/1000 Mb/s Gigabit Combo (Ethernet/SFP)

Protocols
Supported Protocols -
Auto-VoIP
Head-of-Line (HOL) Blocking
IGMP Snooping
Link Aggregation
Port Mirroring

Queuing -
Strict Priority, Weighted Round Robin (WRR)

Jumbo Frames Support - 9,000 Bytes
MAC Address Table Size - 8K
VLAN Groups - 128
VLAN IDs - 4096

Security
Security Features -
DHCP Snooping
RADIUS Authentication

SNMP Support - 1, 2c

Standards
Supported IEEE Standards - 802.1d, 802.1p, 802.1q/p, 802.1w, 802.1x, 802.3, 802.3ab, 802.3ad, 802.3af, 802.3at, 802.3az, 802.3u, 802.3x, 802.3z

Performance
Forwarding Rate - 38.69 Mpps
Switching Bandwidth - 52 Gb/s
Priority Queues - 4

Computer
Memory - 128 MB

Electrical
Power Draw - 17.62 W (Active)
Current - 1 A
AC Input Power - 100 to 240 VAC, 50 / 60 Hz

Environmental
Operating Temperature - 32 to 122°F / 0 to 50°C
Operating Humidity - 10 to 90%
Storage Temperature - -40 to 158°F / -40 to 70°C
Storage Humidity - 10 to 90%

General
Indicator Lights - Link/Activity, System
Dimensions - 17.3 x 7.9 x 1.7" / 44 x 20 x 4.4 cm
Weight - 5 lb / 2 kg

Packaging Info
Package Weight - 6.9 lb
Box Dimensions (LxWxH) - 19.8 x 11.8 x 3.7"
