True Dolby Atmos Surround Sound
Immerse yourself in theater-quality 3D sound. With two up-firing drivers, the JBL Bar 800 delivers true Dolby Atmos 3D surround sound

Real surround sound with detachable surround speakers
Enjoy real surround sound without the hassle of extra wires and power connections. Just place the two detachable battery-powered surround speakers behind you and get swept away in amazing audio.

Built-In Wi-Fi with AirPlay, Alexa Multi-Room Music and Chromecast built-in
Get ready to explore. Access over 300 online music streaming services through AirPlay, Alexa MRM and Chromecast built-in. Enjoy all of your favorite audio content, Internet radio, and podcasts in high definition. The Wi-Fi connection also allows automatic software updates, so you can always enjoy the latest features.

Make movie night soar and let your music move you to new heights with 720W of total output power and thrilling bass from the 10" subwoofer. The JBL Bar 800 with Dolby Atmos includes two up-firing drivers and detachable battery-powered surround speakers to create an immersive 3D cinema experience without having to draw extra cables. You'll never miss a word with our PureVoice technology, which makes sure dialogues are clear even when other sounds are at their loudest. And when you're ready to cut loose, stream your favorite music from AirPlay, Alexa MRM, or Chromecast built-in. Your get-togethers will never be the same.

General Specifications
Power supply
100 - 240V AC, ~ 50/60Hz

Networked standby power
< 2.0W

Operating temperature
0°C - 45°C

Audio Specifications
Total speaker power output (Max @THD 1%)
720W

Soundbar output power (Max @THD 1%)
340W

Surround speaker output power (Max @THD 1%)
2x 40W

Subwoofer output power (Max. @THD 1%)
300 W

Soundbar transducer
3x (46x90)mm racetrack drivers, 3x 0.75" (20mm) tweeters, 2x 2.75" (70mm) up-firing full-range drivers

Surround speaker transducer
1x (46x90)mm racetrack driver

Subwoofer transducer
10” (260mm)

Frequency response
35Hz - 20kHz (-6dB)

Audio inputs
1 Optical, Bluetooth, Chromecast Built-in, AirPlay and Alexa MRM,

Dimensions
Total soundbar dimensions (W x H x D)
1174 x 56 x 120 mm / 46.2" x 2.2" x 4.7"

Main soundbar dimensions (W x H x D)
884 x 56 x 120 mm / 34.8" x 2.2" x 4.7"

Detachable surround speaker dimensions (each) (W x H x D)
145 x 56 x 120 mm / 5.7" x 2.2" x 4.7"

Subwoofer dimensions (W x H x D)
305 x 440.4 x 305 mm / 12" x 17.3" x 12"

Soundbar weight
3.4 kg / 7.4 lbs

Detachable surround speaker weight (each)
1.3 kg / 2.8 lbs

Subwoofer weight
10 kg / 22 lbs

Packaging dimensions (W x H x D)
1000 x 375 x 475 mm/ 39.4" x 14.8" x 18.7"

Packaging Weight
18.9 kg / 41.6 lbs

Control and Connection Specifications
USB port
Type A

USB rating
5V DC, 0.5A

Supporting file format
MP3
MP3 codec
MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3

MP3 sampling rate
16 - 48 kHz

MP3 bitrate
80 - 320 kpbs

Bluetooth version
5.0

Bluetooth profile
A2DP 1.2, AVRCP 1.5

Bluetooth transmitter frequency range
2400MHz – 2483.5MHz

Bluetooth transmitter power
<15dBm (EIRP)

Wi-Fi network
IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)

2.4G Wi-Fi transmitter frequency range
2412 - 2472MHz

2.4G Wi-Fi transmitter power
< 20dBm (EIRP)

5G Wi-Fi transmitter frequency range
5.15 - 5.35GHz, 5.470-5.725GHz, 5.725 - 5.825GHz

5G Wi-Fi transmitter power
5.15-5.25GHz <23dBm, 5.25-5.35GHz & 5.47-5.725GHz <20dBm, 5.725-5.825GHz <14dBm (EIRP)

2.4G wireless transmitter frequency range
2406 - 2474MH

2.4G wireless transmitter power
＜10dBm (EIRP）

Battery
Lithium battery
3.635V, 3283mAh
