Dolby Atmos and MultiBeam Surround Sound
Immerse yourself in theater-quality 3D surround sound. Hear extraordinary sound effects from everywhere in the room, without the need for extra surround speakers

Built-In Wi-Fi with AirPlay, Alexa Multi-Room Music and Chromecast built-in
Get ready to explore. Access over 300 online music streaming services through AirPlay, Alexa MRM and Chromecast built-in. Enjoy all of your favorite audio content, Internet radio, and podcasts in high definition. The Wi-Fi connection also allows automatic software updates, so you can always enjoy the latest features.

590W output power
With 590 watts of total system output power, the JBL Bar 500 transforms your movies, music and games into immersive sound experiences

What's on the menu tonight? Movies, music or gaming? The JBL Bar 500 brings your movies to life with MultiBeam and Dolby Atmos 3D surround sound. While PureVoice technology optimizes voice clarity to ensure you never miss a word. Feel the thrilling bass from the wireless 10" subwoofer. And with AirPlay, Alexa Multi-Room Music (MRM) and Chromecast built-in, you've got over 300 easy streaming options to choose from, whether you want to dance or you're ready to relax. Whatever you're in the mood for, the JBL Bar 500's got you covered.

General Specifications
Power supply
100 - 240V AC, ~ 50/60Hz
Networked standby power
< 2.0 W
Operating temperature
0°C - 45 °C

Audio Specifications
Total speaker power output (Max @THD 1%)
590W
Soundbar output power (Max @THD 1%)
290W
Subwoofer output power (Max. @THD 1%)
300 W
Soundbar transducer
4x (46x90)mm racetrack drivers, 3x 0.75" (20mm) tweeters
Subwoofer transducer
10” (260mm)
Frequency response
35Hz - 20kHz (-6dB)
Audio inputs
1 Optical, Bluetooth, USB (USB playback is available in US version. For other versions, USB is for Service only.)

Dimensions
Soundbar dimensions (W x H x D)
1017 x 56 x 103.5 mm / 40’’ x 2.2’’ x 4’’

Subwoofer dimensions (W x H x D)
305 x 440.4 x 305 mm / 12" x 17.3" x 12"

Soundbar weight
2.8kg/ 6.2 lbs

Subwoofer weight
10 kg / 22 lbs

Packaging dimensions (W x H x D)
1105 x 370 x 475 mm/ 43.5" x 14.6" x 18.7"

Packaging Weight
16.2 kg / 35.6 lbs

Control and Connection Specifications
USB port
Type A

USB rating
5V DC, 0.5A

Supporting file format
MP3
MP3 codec
MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3

MP3 sampling rate
16 - 48 kHz

MP3 bitrate
80 - 320 kpbs

Bluetooth version
5.0

Bluetooth profile
A2DP 1.2, AVRCP 1.5

Bluetooth transmitter frequency range
2400 MHz – 2483.5 MHz

Bluetooth transmitter power
<15 dBm (EIRP)

Wi-Fi network
IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)

2.4G Wi-Fi transmitter frequency range
2412 - 2472 MHz

2.4G Wi-Fi transmitter power
< 20 dBm (EIRP)

5G Wi-Fi transmitter frequency range
5.15 - 5.35GHz, 5.470-5.725GHz, 5.725 - 5.825GHz

5G Wi-Fi transmitter power
5.15-5.25GHz <23dBm, 5.25-5.35GHz & 5.47-5.725GHz <20dBm, 5.725-5.825GHz <14dBm (EIRP)

2.4G wireless transmitter frequency range
2406 - 2474MH

2.4G wireless transmitter power
＜10dBm (EIRP）
