CPU Specifications
Total Cores
10

Total Threads
20

Max Turbo Frequency
5.20 GHz

Intel® Thermal Velocity Boost Frequency
5.20 GHz

Intel® Turbo Boost Max Technology 3.0 Frequency
5.10 GHz

Intel® Turbo Boost Technology 2.0 Frequency
5.00 GHz

Processor Base Frequency
2.80 GHz

Cache
20 MB Intel® Smart Cache

Bus Speed
8 GT/s

TDP
65 W

Supplemental Information
Embedded Options Available
No

Datasheet
View now

Memory Specifications
Max Memory Size (dependent on memory type)
128 GB

Memory Types
DDR4-2933

Max # of Memory Channels
2

Max Memory Bandwidth
45.8 GB/s

ECC Memory Supported
No

Processor Graphics
Processor Graphics
Intel® UHD Graphics 630

Graphics Base Frequency
350 MHz

Graphics Max Dynamic Frequency
1.20 GHz

Graphics Video Max Memory
64 GB

4K Support
Yes, at 60Hz

Max Resolution (HDMI)
4096 x 2160@30Hz

Max Resolution (DP)
4096 x 2304@60Hz

Max Resolution (eDP - Integrated Flat Panel)
4096 x 2304@60Hz

DirectX* Support
12

OpenGL* Support
4.5

Intel® Quick Sync Video
Yes

Intel® InTru™ 3D Technology
Yes

Intel® Clear Video HD Technology
Yes

Intel® Clear Video Technology
Yes

# of Displays Supported
3

Device ID
0x9BC5

Expansion Options
Scalability
1S Only

PCI Express Revision
3.0

PCI Express Configurations
Up to 1x16, 2x8, 1x8+2x4

Max # of PCI Express Lanes
16

Package Specifications
Sockets Supported
FCLGA1200

Max CPU Configuration
1

Thermal Solution Specification
PCG 2015C

Intel® Thermal Velocity Boost Temperature
70 °C

TJUNCTION
100°C

Package Size
37.5mm x 37.5mm

Advanced Technologies
Intel® Optane™ Memory Supported
Yes

Intel® Thermal Velocity Boost
Yes

Intel® Turbo Boost Max Technology 3.0
Yes

Intel® Turbo Boost Technology
2.0

Intel® Hyper-Threading Technology
Yes

Intel® Transactional Synchronization Extensions
No

Intel® 64
Yes

Instruction Set
64-bit

Instruction Set Extensions
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2

Idle States
Yes

Enhanced Intel SpeedStep® Technology
Yes

Thermal Monitoring Technologies
Yes

Intel® Identity Protection Technology
Yes

Security & Reliability
Intel vPro® Platform Eligibility
Yes

Intel® AES New Instructions
Yes

Secure Key
Yes

Intel® Software Guard Extensions (Intel® SGX)
Yes with Intel® ME

Intel® OS Guard
Yes

Intel® Trusted Execution Technology
Yes

Execute Disable Bit
Yes

Intel® Boot Guard
Yes

Intel® Stable IT Platform Program (SIPP)
Yes

Intel® Virtualization Technology (VT-x)
Yes

Intel® Virtualization Technology for Directed I/O (VT-d)
Yes

Intel® VT-x with Extended Page Tables (EPT)
Yes
