CPU Specifications
Total Cores
10

# of Performance-cores
6

# of Efficient-cores
4

Total Threads
16

Max Turbo Frequency
4.90 GHz

Performance-core Max Turbo Frequency
4.90 GHz

Efficient-core Max Turbo Frequency
3.60 GHz

Performance-core Base Frequency
3.70 GHz

Efficient-core Base Frequency
2.80 GHz

Cache
20 MB Intel® Smart Cache

Total L2 Cache
9.5 MB

Processor Base Power
125 W

Maximum Turbo Power
150 W

Memory Specifications
Max Memory Size (dependent on memory type)
128 GB

Memory Types
Up to DDR5 4800 MT/s
Up to DDR4 3200 MT/s

Max # of Memory Channels
2

Max Memory Bandwidth
76.8 GB/s

ECC Memory Supported
Yes

Processor Graphics
Processor Graphics
Intel® UHD Graphics 770

Graphics Base Frequency
300 MHz

Graphics Max Dynamic Frequency
1.45 GHz

Graphics Output
eDP 1.4b, DP 1.4a, HDMI 2.1

Execution Units
32

Max Resolution (HDMI)‡
4096 x 2160 @ 60Hz

Max Resolution (DP)‡
7680 x 4320 @ 60Hz

Max Resolution (eDP - Integrated Flat Panel)‡
5120 x 3200 @ 120Hz

DirectX* Support
12

OpenGL* Support
4.5

OpenCL* Support
3.0

Multi-Format Codec Engines
2

Intel® Quick Sync Video
Yes

Intel® Clear Video HD Technology
Yes

# of Displays Supported
4

Device ID
0x4680

Expansion Options
Direct Media Interface (DMI) Revision
4.0

Max # of DMI Lanes
8

Scalability
1S Only

PCI Express Revision
5.0 and 4.0

PCI Express Configurations
Up to 1x16+4, 2x8+4

Max # of PCI Express Lanes
20

Package Specifications
Sockets Supported
FCLGA1700

Max CPU Configuration
1

Thermal Solution Specification
PCG 2020A

TJUNCTION
100°C

Package Size
45.0 mm x 37.5 mm

Advanced Technologies
Intel® Gaussian & Neural Accelerator
3.0

Intel® Thread Director
Yes

Intel® Deep Learning Boost (Intel® DL Boost)
Yes

Intel® Optane™ Memory Supported
Yes

Intel® Speed Shift Technology
Yes

Intel® Turbo Boost Max Technology 3.0
No

Intel® Turbo Boost Technology
2.0

Intel® Hyper-Threading Technology
Yes

Intel® 64
Yes

Instruction Set
64-bit

Instruction Set Extensions
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2

Idle States
Yes

Enhanced Intel SpeedStep® Technology
Yes

Thermal Monitoring Technologies
Yes

Intel® Volume Management Device (VMD)
Yes

Security & Reliability
Intel vPro® Eligibility
Intel vPro® Enterprise

Intel® Threat Detection Technology (TDT)
Yes

Intel® Active Management Technology (AMT)
Yes

Intel® Standard Manageability (ISM)
Yes

Intel® One-Click Recovery
Yes

Intel® Hardware Shield Eligibility
Yes

Intel® Control-Flow Enforcement Technology
Yes

Intel® Total Memory Encryption - Multi Key
Yes

Intel® Total Memory Encryption
Yes

Intel® AES New Instructions
Yes

Secure Key
Yes

Intel® OS Guard
Yes

Intel® Trusted Execution Technology
Yes

Execute Disable Bit
Yes

Intel® Boot Guard
Yes

Mode-based Execute Control (MBEC)
Yes

Intel® Stable IT Platform Program (SIPP)
Yes

Intel® Virtualization Technology with Redirect Protection (VT-rp)
Yes

Intel® Virtualization Technology (VT-x)
Yes

Intel® Virtualization Technology for Directed I/O (VT-d)
Yes

Intel® VT-x with Extended Page Tables (EPT)
Yes
