Intelligent PoE Management. When the power supply exceeds the limit, PoE ports intelligently manage the power supply, which extends the switch lifetime.

Up to 300 m Long Range PoE Transmission. The distance between IPCs and switch can reach maximum 300 meters.

4/8-Core Adaptive Power Supply with Less Power Loss. 8-core power supply reduces the power loss on cables.

6KV Surge Protection to Improve Reliability in Harsh Environment. The built-in surge protection device protects the switch from the sudden lightning surge in harsh environment.

Design for Video Transmission. VIP port ensures important data transmission when network congestion occurs.

General
Shell: Metal material
Net Weight: 0.2 kg (0.4 lb)
Gross Weight: 0.48 kg (1.06 lb)
Dimensions (W × H × D): 105 mm × 27.6 mm × 83.1 mm (4.1'' × 1.1'' × 3.3'')
Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
Storage Temperature: –40 °C to 85 °C (–40 °F to 185 °F)
Operating Humidity: 5% to 95% (no condensation)
Relative Humidity: 5% to 95% (no condensation)
Power Supply: 48 VDC, 0.8 A
Max. Power Consumption: 38 W
Power Consumption in Idle: 3 W
Installation Mode: Desk-Mounted,Wall-Mounted
Surge Protection: 6 KV

Network Parameters
Ports: 4 x 10/100 Mbps PoE port,1× 10/100 Mbps RJ45 port
MAC Address Table: 2 K
Switching Capacity: 1 Gbps
Packet Forwarding Rate: 0.74 Mpps
Internal Cache: 768 Kbits

PoE Power Supply
PoE Standard: IEEE 802.3af;IEEE 802.3at
PoE Power Pin: 8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
PoE Port: PoE: Ports 1 to 4
Max. Port Power: 30 W
PoE Power Budget: 35 W

Dialing Function
Long Range: : Ports 1 to 4 : up to 300 m.
Long range performance may vary depend on camera model or cable condition.
