16 x 1000M Ethernet ports
Supports IEEE 802.3, IEEE 802.3u and IEEE 802.3x
1000M network access
Wire-speed forwarding and non-blocking design
Store-and-forward switching
Solid high-strength metal shell
Fan-free design with high reliability

Network Parameters
Ports
16 × gigabit RJ45 ports

Port Type
RJ45 port, Full duplex, MDI/MDI-X adaptive

Standard
IEEE 802.3, IEEE 802.3u, IEEE 802.3x

Forwarding Mode
Store-and-forward switching

MAC Address Table
8 K

Switching Capacity
32 Gbps

Packet Forwarding Rate
23.808 Mpps

Internal Cache
4.1 Mbits

General
Dimensions (W × H × D)
257 mm × 44.5 mm × 175.8 mm (10.1” × 1.8” × 6.9”)

Shell
Metal material, fan-free design

Gross Weight
2.07 kg (4.56 lb)

Net Weight
1.20 kg (2.60 lb)

Operating Temperature
0 °C to 40 °C (32 °F to 104 °F)

Storage Temperature
–40 °C to 85 °C (–40 °F to 185 °F)

Storage Humidity
5% to 95% (no condensation)

Power Supply
220 VAC，50/60 Hz，Max. 0.3 A
