Up to 16-ch IP camera inputs
H.265+/H.265/H.264+/H.264 video formats
Up to 2-ch@8 MP/4-ch@4 MP/8-ch@1080p decoding capacity
Up to 160 Mbps incoming bandwidth

Motion Detection 2.0
Human/Vehicle Analysis: 4-ch

Video and Audio
IP Video Input: 16-ch
Incoming Bandwidth: 160 Mbps
Outgoing Bandwidth: 80 Mbps
HDMI Output: 1-ch, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz; ,HDMI/VGA simultaneous output,

VGA Output:
1-ch, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz ;,HDMI/VGA simultaneous output,

Video Output Mode: HDMI/VGA simultaneous output
Audio Output: 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 k Ω)

Recording
Stream Type: Video, Video & Audio
Audio Compression: G.711ulaw/G.711alaw/G.722/G.726

Decoding
Decoding Format: H.265+,H.265,H.264+,H.264
Recording Resolution: 8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF

Decoding Capability:
AI&4K Off: 8-ch@1080p(30fps)
AI/4K On: 6-ch@1080p(30fps)
*: The length or width of camera resolution (each track) cannot exceed 4096 pixels.

Synchronous playback: 16-ch

Network
Remote Connection: 32
Network Protocol: TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
Network Interface: 1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

PoE
Interface: 16, RJ-45 10/100 Mbps self-adaptive Ethernet interfaces
Power: ≤ 150W
Standard: IEEE 802.3 af/at

Auxiliary Interface
SATA: 2 SATA interfaces
Capacity: Up to 8 TB capacity for each disk
USB Interface: 2 × USB 2.0
Alarm In/Out: N/A (4/1 is optional)

General
Power Supply: AC100V~240V，190W
Consumption: ≤ 10 W (without enabling PoE)
Working Temperature: -10 to +55º C (+14 to +131º F)
Working Humidity: 10 to 90 %
Dimension (W × D × H): 384 × 315 × 52 mm (15.12" × 12.38" × 2.03")
≤ 3.7 kg (8.1 lb)
