802.1X - Yes
Port based 802.1X Authentication - Yes
Authentication for Management Access - Yes
RADIUS - Yes
Trusted Host - Yes
Max Access Control List (ACL) Entries - Yes
MAC Access List - Yes
IP Access List - Yes
IPv6 Access List - Yes
Port-based Bandwidth Control - Yes
Class of Service (CoS) - Yes
802.3x Flow Control - Yes
Head-of-line (HOL) Blocking Prevention - Yes
Store & Forwarding Forwading - Yes
Comply with RoHS 6 - Yes
Energy Efficiency Ethernet (EEE) - Yes
Power Saving By Link Status - Yes
Power Saving By Cable Length - Yes
Power Saving By Port Shut-Off - Yes
Power Saving By System Hibernation - Yes
1000Base-T Interface - 8
1000M SFP Interface - 2
Auto MDI/MDIX - Yes
10/100/1000BASE-T ports - 8
SFP ports - 2
CPU Speed - 500MHz
DRAM Size - DDR3 128MB
Flash Memory Size - 32MB
Packet Buffer Size - 4.1MBits
FAN - Fanless
Jumbo Frame - 10,000 Bytes
Loopback Detection (LBD) - Yes
MAC Address Table Size - 8K
IGMP Snooping - Yes
Max IGMP Snooping Groups - 256
IGMP Snooping Fast Leave - Yes
MLD Snooping - Yes
MLD Snooping Groups - Yes
MLD Snooping Fast Leave - Yes
IP Interface - Yes
Max Number of IP Interface - 4
ARP - Yes
ARP Entries - Yes
IPv6 Neighbor Discovery (ND) - Yes
ND Entries - 128
Default Route - Yes
Static Route - Yes
802.3ad Link Aggregation - Yes
Link Aggregation Group Per Device - 8
Max Port Per Link Aggregation Group - 8
Web-based GUI - Yes
Telnet Server - Yes
SNMP - Yes
TFTP Client - Yes
SNMP Trap - Yes
System Log - Yes
RMONv1 - Yes
LLDP - Yes
D-Link Discover Protocol (DDP) - Yes (v0.26)
LLDP-MED - Yes
DHCP/BootP Client - Yes
DHCP relay - Yes
Dual Configurations - Yes
Dual Images - Yes
Debug Command - Yes
Ping - Yes
D-Link Network Assistant - Yes (Chrome edition)
Smart Wizard - Yes
Port Mirroring - Yes
Cable Diagnostics - Yes
Switch Capacity - 20 Gbps
Max. Packet Forwarding Rate - 14.88 Mpps
Power Input - 100-240 VAC
Number of Queue - Yes
Strict Priority Queue (SPQ) - Yes
Weighted Round Robin (WRR) - Yes
SSH - Yes
SSL - Yes (only support TLS 1.0)
Port Security - Yes
Broadcast/Multicast/Unicast Storm Control - Yes
Traffic Segmentation - Yes
Smart IP-MAC-Port Binding (Smart IMPB) - Yes
D-Link Safeguard Engine - Yes
DHCP Server Screening - Yes
ARP Spoofing Prevention - Yes
DoS Attack Prevention - Yes
802.1D Spanning Tree (STP) - Yes
802.1w Rapid Spanning Tree (RSTP) - Yes
802.1s Multiple Spanning Tree (MSTP) - Yes
Root Restriction - Yes
Maximum Heat Dissipation - 21.53 BTU/hr (100V) <br>21.59 BTU/hr (240V)
Acoustic - 0 dB
Dimension - 280mm x 126 mm x 44mm
Maximum Power Consumption - 6.31 W/100 V<br> 6.33 W/240 V
MTBF - 1,380,058 hours
Operating Altitude - 1500 meters
Operation Humidity - 0% - 95% RH
Operation Temperature - -5 - 50°C
Standby Power Consumption - 2.03 W/100V / 2.07 W/240V
Storage Humidity - 0% ~ 95% RH
Storage Temperature - -20-70°C
Weight - 0.98 kg
Simple Network Time Protocol (SNTP) - Yes
802.1Q VLAN - Yes
VLAN Groups - Yes
Port-based VLAN - Yes
Voice VLAN - Yes
Auto Surveillance VLAN - Yes
Asymmetric VLAN - Yes
