24-Port Fast Ethernet Unmanaged Switch
DES-1024D
Enhance your workgroup performance with highly flexible connectivity.

IEEE802.3az EEE (Energy Efficient Ethernet)
EnergyStar Level V-certified
RoHS compliant
Plug-and-play
Full/half-duplex for Ethernet/Fast Ethernet speeds
IEEE 802.3x Flow Control

Powerful, Flexible Workgroup Performance
The DES-1016D and DES-1024D offer an economical way for SOHO and small to medium businesses (SMB) to benefit from high-speed networking. They provide up to twenty-four ports for easy expansion of your network and a quick way to upgrade your network to Fast Ethernet connectivity. The switches speed up file transfer times, improve slow and sluggish networks, keep your vital business applications available, and help your employees respond more quickly to customers and each other.

Expand and Upgrade Your Network
Easily expand your network by adding more computers or devices with speeds up to 200 Mbps per port in full-duplex mode.

Conserve Energy
The switches help you conserve energy through IEEE802.3az EEE, which works when both the switch and its link partner are EEE-compliant devices. This power-saving feature automatically puts the switch into a low-power idle state when the switch utilization is zero, allowing you to lower your energy usage and save on your energy costs.

Designed with the Environment in Mind
The DES-1016D and DES-1024D are compliant with Energy Star Level V, as well as with the stringent CEC and MEPS regulations that require the use of energy efficient power adapters. They use recyclable packaging that helps reduce waste, complying with the WEEE directive. Their innovative design lets them run cool and quiet without sacrificing performance.

100Base-TX Interface - 24
Auto MDI/MDIX - Yes
Switching Capacity - 4.8 Gbps
Max. Packet Forwarding Rate - 3.57 Mpps
Store & Forwarding Forwading - Yes
Dimension - 280 × 150 × 44 mm
Weight - 1.14 kg
Operation Temperature - 0 ~ 40 °C
Storage Temperature - - 20 ~ 70 °C
Operation Humidity - 0% ~ 90% RH
Storage Humidity - 5% ~ 90% RH
Maximum Power Consumption - 2.8 Watts
Operating Altitude - 2000m and 40 degree C +/- 2 & Humidity 92%
Standby Power Consumption - 1.17 Watts
Acoustic - 0 dB
Power Input - AC：100 ~ 240 V
Packet Buffer Size - 2 MB
FAN - Fanless
Energy Efficiency Ethernet (EEE) - Yes
Comply with RoHS 6 - Yes
Power Saving By Link Status - Yes
MAC Address Table Size - 8K
802.3x Flow Control - Yes
Head-of-line (HOL) Blocking Prevention - Yes
Number of Queue - 4
