80 Plus Gold Efficiency
2 EPS Connectors
120mm HDB Fan
High Temperature Resilience
Full Modular Cabling

80 PLUS GOLD CERTIFIED
Efficiency has always been one of the most important factors for users when choosing their power supply unit. While there are a range of efficiency options, 80 PLUS Gold has been the ideal choice for the last several years and continues to be seen as the standard for much of the world. The MWE Gold - V2 delivers an 80 PLUS Gold certification, guaranteeing a typical minimum efficiency of 90%.

ATX VERSION
ATX 12V

PFC
Active PFC

INPUT VOLTAGE
90-264V

INPUT CURRENT
12-6A

INPUT FREQUENCY
47-63Hz

DIMENSIONS (L X W X H)
160 x 150 x 86 mm

FAN SIZE
120mm

FAN BEARING
HDB

FAN SPEED
1500 RPM

NOISE LEVEL @ 20%
0 dBA

NOISE LEVEL @ 50%
17.8 dBA

NOISE LEVEL @ 100%
25.9 dBA

EFFICIENCY
90% @ Typical Load

80 PLUS RATING
80 PLUS Gold

ERP 2014 LOT 3
Yes

OPERATING TEMPERATURE
0-50°C

POWER GOOD SIGNAL
100 - 150 ms

HOLD UP TIME
>16ms at 100% Load

MTBF
>100,000 Hours

PROTECTIONS
OVP, OPP, OTP, SCP, OCP, UVP

REGULATORY
TUV, CE, CCC, EAC, RCM, cTUVus, FCC, BSMI

ATX 24-PIN CONNECTORS
1

EPS 4+4 PIN CONNECTORS
1

EPS 8 PIN CONNECTOR
1

SATA CONNECTORS
12

PERIPHERAL 4-PIN CONNECTORS
4

PCI-E 6+2 PIN CONNECTORS
4

SERIES
MWE Gold Series
80 PLUS
Gold

MODULAR
Full Modular

WATTAGE
Above 750W
