Built For The Long Haul
TUF Gaming series PSUs bring military-grade components and a robust cooling solution together to create a power platform you can depend on. High-quality capacitors and chokes undergo a myriad of tests, including extreme temperatures and vibration tests, to ensure they meet rigorous military specifications. An Axial-tech fan with a dual ball fan bearing design offers more longevity than other fan types, increasing the overall lifespan of the product. It’s the perfect PSU to slot into a TUF Gaming rig or any DIY build designed to power through AAA games for years to come.
All critical capacitors and chokes in TUF Gaming PSUs are certified to military-grade specifications, ensuring reliable operation over a wide range of temperatures.
Dual Ball Fan Bearings
2x longer lifespan
Exemplary cooling is provided by a 135mm fan spinning on a dual ball bearing setup that will last up to twice as long as a sleeve bearing
Protective PCB Coating
All wrapped up
A protective conformal coating envelops the PCB to protect against short-circuits caused by moisture, dust, and debris.
80 Plus Bronze Certification
Brains and Bronze
The high-quality components used in TUF Gaming power supplies ensure efficient and reliable operation worthy of an 80 PLUS Bronze Certification. The efficiency also leads to low temperatures within the PSU, facilitating an even quieter acoustic profile for the 135mm Axial-tech fan.
Axial−tech Fan Design
Better, faster, stronger
Originally developed for top-end ROG graphics cards, Axial-tech fan design features a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure. For TUF Gaming series PSUs, we’ve scaled that design to 135mm so it keeps things cool at low RPMs while producing less noise.
An onboard controller brings the 135mm fan to a standstill when thermal design power (TDP) is below 30%, letting you enjoy light gaming in relative silence. Above 30% TDP, the fans automatically start up again.
Intel Specification - ATX12V
Dimensions - 15 x 15 x 8.6 Centimeter
Efficiency - 80Plus Bronze
Protection Features - OPP/OVP/UVP/SCP/OCP/OTP
Hazardous Materials - ROHS
AC Input Range - 100-240Vac
DC Output Voltage - +3.3V +5V +12V -12V +5Vsb
Maximum Load - 25A 25A 62A 0.8A 3A
Total Output - 650W
MB 24/20-pin x1
CPU 4+4-pin x2
PCI-E 6+2-pin x4
Package Contents - Power Cord x1
Motherboard Power Cable x1 (600mm
CPU Cable x2 (800mm)
PCI-E Cable x2 (600mm)
SATA Cable x2 (400+120mm x1, 400+120+120mm x1)
Periphreal x1 (400+150+150+150mm)
TUF Gaming sticker x1
Weight Single PSU : 2.06KG
Product Weight (with packing) : 2.75KG
