Super-fast concurrent dual-band 802.11ac Wi-Fi at up to 1167 Mbps
Improved coverage and multi-device performance with four external 5dBi antennas — two each for the 2.4 GHz and 5 GHz bands
USB 2.0 port supports AiPlayer for music streaming
Help your children stay safe online with Parental Control

Super-fast concurrent Wi-Fi
Powered by 5th-generation Wi-Fi (5G Wi-Fi), the new 802.11ac chipset gives the RT-AC1200 super-fast wireless speeds. RT-AC1200 delivers up to 867 Mbps at 5 GHz, which is 3X faster than current 802.11n 2x2 routers

Add external storage to your network
Make RT-AC1200 your media and file center. With USB 2.0 ports, you can connect external storage drives and stream media content to your networked PCs. Networking you storage devices lets you access them easier than ever before.

Easy 3-step setup
Use your laptop, tablet, or PC to set up your ASUS router effortlessly in only 3 easy steps. Simply connect the cables to the router, open a web browser, and follow the setup wizard to get connected to the internet in no time.

Monitor and restrict Internet activity for any user
Advanced parental control helps you protect your children from Internet addiction. You can restrict the times that each device can access the internet by applying scheduled time limits.

Take control of your media with convenient wireless streaming
With the ASUS AiPlayer app, RT-AC1200 becomes your home media hub. You can store all your music, videos and images in the attached USB storage and stream it wirelessly to any mobile device — no more running out of space on your mobile. Enjoy your collections in any room, and with support for almost any format you’ll enjoy smooth, effortless streaming.

Model Name
RT-AC1200

Network Standard
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
IPv4
IPv6

Data Rate
802.11a : up to 54 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
802.11n : up to 300 Mbps
802.11n : up to 600 Mbps
802.11ac : up to 867 Mbps

Antenna
External antenna x 4

Operating Frequency
2.4G Hz / 5 GHz

Ports
RJ45 for 10/100 BaseT for WAN x 1, RJ45 for 10/100 BaseT for LAN x 4

USB 2.0 x 1

Button
WPS Button, Reset Button, Power Button

LED Indicator
Power x 1
Wi-Fi x 2
USB x 1
WAN x 1
LAN x 4

Power Supply
AC Input : 110V~240V(50~60Hz)
DC Output : 12 V with max. 1.5 A current

Product Weight (g)
0.65 lb

AiMesh
AiMesh : No
Primary AiMesh router : No
AiMesh node : No

Router APP
ASUS Router APP : Yes

Game
Game Boost/acceleration : No
WTFast : No

Alexa
Support Alexa skil : No

IFTTT
Support IFTTT : No

AiProtection
AiProtection : No
Router Security Assessment : No
Malicious site blocking : No
Two-Way IPS : No
Infected Device Prevention and Blocking ; No

Parental Control
Parental Control : Yes
Parental Control Customized Internet schedule : Yes

Traffic Control
Adaptive QoS : No
Bandwidth Monitor : Yes
Bandwidth limiter : Yes
Maximum Bandwidth limiter rule : 32
Traditional QoS : Yes
Maximum Traditional QoS rule : 32
Traffic Monitor : Yes
Real-time traffic monitor : Yes
Wired Traffic Monitor : Yes
Wireless Traffic Monitor : Yes
Traffic Analyzer : Yes
Traffic analysis period : Daily, Weekly, Monthly
Website history : No

Wireless
IPv6 : Yes
MU-MIMO : No
Wi-Fi Encryption : Open system, WPA/WPA2-Personal, WPA/WPA2-Enterprise
UTF-8 SSID : No
Guest Network : Yes
Maximum Guest Network rule : 2.4GHz x3, 5GHz x3
Guest Network Encryption : Open system, WPA/WPA2-Personal
WPS : Yes
Wi-Fi MAC address filter : Yes
Maximum MAC filters : 64
Wireless scheduler : Yes
Airtime fairness : Yes
RADIUS Server : Yes
Universal beamforming : Yes
Explicit beamforming : Yes
IGMP snooping : Yes

WAN
Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP
Dual WAN : No
WAN Aggregation : No
3G/4G LTE dongle : Yes
Android tethering : Yes
Port forwarding : Yes
Maximum port forwarding rule : 64
Port triggering : Yes
Maximum port triggering rule : 32
DMZ : Yes
DDNS : Yes
NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough,PPPoE relay

LAN
DHCP Server : Yes
IPTV : No
LAN Link Aggregation : No
Manually assign IP address : Yes
Maximum manually assign IP address rule : 64

VPN
VPN Client L2PT : No
VPN Client OVPN : No
VPN Client PPTP : No
VPN Server IPSec : No
VPN Server OVPN : No
VPN Server PPTP : No
VPN Fusion : No
USB application
File System : FAT16, FAT32, NT3G
3G/4G LTE dongle : Yes
HDD hibernation : Yes
Safely Remove disk : Yes
AiCloud : No
Download master : No
AiDisk : No
Media Server : Yes
Time Machine : No
Samba Server : Yes
FTP Server : Yes
Shared Folder privileges : Yes

Administration
Operating mode : Accesspoint, Router
Operating system : ASUSWRT
Free OS upgrade : Yes
Firewall : Yes
Maximum Firewall keyword filter : 64
Maximum Firewall network service filter : 32
Maximum Firewall URL filter : 64
Wake on LAN (WOL) : Yes
SSH : Yes
Configuration backup and restore : Yes
Diagnosis tools : Yes
Feedback system : Yes
System log : Yes
