Audible alarms
Provides notification of changing utility power and UPS power conditions

Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.

Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance

Battery replacement without tools
Enables fast battery replacement, lowering Mean Time to Repair (MTTR).

Battery-protected and surge-only outlets
Reserves power capacity and run time for connected equipment that require UPS battery back-up while providing surge only
protection for less critical equipment
Boost and Trim Automatic Voltage Regulation (AVR)
Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).

Cold-start capable
Provides temporary battery power when the utility power is out.

Dataline surge protection
Provides protection of connected equipment from power surges on the data lines.

Disconnected battery notification
Warns when a battery is not available to provide backup power.

Hot-swappable batteries
Ensures clean, uninterrupted power to protected equipment while batteries are being replaced

LCD graphics display
Text and mimic diagrams that display modes of operation, system parameters and alarms.

Output
Max Configurable Power (Watts)
540 Watts / 900VA

Output Frequency (sync to mains)
50/60 Hz +/- 1 Hz Sync to mains

Topology
Line interactive

Waveform type
Stepped approximation to a sinewave

Transfer Time
10 ms typical : 12 ms maximum

Input
Input frequency
50/60 Hz +/- 3 Hz Auto-sensing

Input voltage range for main operations
176 - 294V

Batteries & Runtime
Battery type
Lead-acid battery

Typical recharge time
12hour(s)

Nominal Battery Voltage
12 V

Expected Battery Life (years)
3 - 5

RBC Quantity
1

Battery Charge Power (Watts)
11 Watts

Communications & Management
Interface Port(s)
USB

Control panel
Multifunction LCD status and control console

Audible Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Surge Protection and Filtering
Data Line Protection
RJ45 network line - 10/100/1000 Base-T Ethernet

Filtering
Full time multi-pole noise filtering : 10% of IEEE surge let-through : zero clamping response time: instantaneous

Physical
Maximum Height
190MM, 19.0CM

Maximum Width
91MM, 9.1CM

Maximum Depth
310MM, 31.0CM

Net Weight
7.1KG

Shipping weight
8.0KG

Shipping Height
255MM, 25.5CM

Shipping Width
143MM, 14.3CM

Shipping Depth
440MM, 44.0CM

Master Carton Dimensions (Length x Width x Height)
279 x 457 x 229MM

Master Carton Units
2.0

Master Carton Weight
16.85
