Protection
Battery and surge protected outlets
Back up and protect your hardware and data during power outages, surges and spikes .
Battery backup and surge protection
Outlets provide abundant runtime for network gateway equipment and other critical low-power devices, allowing for hours of internet access during a power outage.

Manageability
LED Indicators
Provide easy-to-read status of the unit and utility power conditions.
Audible alarms
Provides notification of changing utility power and UPS power conditions

Safety
Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.

Features
Sleek design
Slim, modern design can be upright, flat, or wall-mounted to comfortably fit any electronics set-up and complement home décor.
Cold-start capable
Provides temporary battery power when the utility power is out.
Transformer-block spaced outlets
Protect equipment with input transformer blocks without blocking access to other receptacles.
Boost Automatic Voltage Regulation (AVR)
Preserves battery life and maximizes runtime by correcting low voltages without discharging the battery.

Output
Max Configurable Power (Watts)
450 Watts / 800VA

Output Frequency (sync to mains)
50/60 Hz +/- 1 Hz Unsynchronised

Topology
Line interactive

Waveform type
Stepped approximation to a sinewave

Transfer Time
6 ms typical : 10 ms maximum

Input
Input frequency
50/60 Hz +/- 5 Hz Auto-sensing

Input voltage range for main operations
170 - 280V

Number of Power Cords
1

Batteries & Runtime
Battery type
Lead-acid battery

Typical recharge time
8hour(s)

Nominal Battery Voltage
12 V

Expected Battery Life (years)
3 - 5

Efficiency
View Efficiency Graph

Communications & Management
Control panel
LED Status display with on line : on battery

Audible Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Surge Protection and Filtering
Surge energy rating
156Joules

Physical
Maximum Height
93MM, 9.25CM

Maximum Width
161MM, 16.05CM

Maximum Depth
305MM, 30.5CM

Net Weight
5.3KG
