Manageability
Audible alarms
Provides notification of changing utility power and UPS power conditions

LED Indicators
Provide easy-to-read status of the unit and utility power conditions.

Features
Sleek design
Slim, modern design can be upright, flat, or wall-mounted to comfortably fit any electronics set-up and complement home décor.

Transformer-block spaced outlets
Protect equipment with input transformer blocks without blocking access to other receptacles.

Boost Automatic Voltage Regulation (AVR)
Preserves battery life and maximizes runtime by correcting low voltages without discharging the battery.

Cold-start capable
Provides temporary battery power when the utility power is out.

Safety
Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.

Protection
Battery and surge protected outlets
Back up and protect your hardware and data during power outages, surges and spikes .

Battery backup and surge protection
Outlets provide abundant runtime for network gateway equipment and other critical low-power devices, allowing for hours of internet access during a power outage.

Availability
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.

Advanced Safety Features
Safeguard your Home UPS from overloads, excessive mains voltages, short circuits, installation mishaps and battery damage due to low voltage situations.

Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance

Output
Max Configurable Power (Watts)
360 Watts / 700VA

Output Frequency (sync to mains)
50/60 Hz +/- 1 Hz Sync to mains

Topology
Line interactive

Waveform type
Stepped approximation to a sinewave

Transfer Time
6 ms typical : 10 ms maximum

Input
Input frequency
50/60 Hz +/- 5 Hz Auto-sensing

Input voltage range for main operations
170 - 280 (230 V) ACV

Number of Power Cords
1

Input Power Factor at Full Load
0.51

Batteries & Runtime
Battery type
Lead-acid battery

Typical recharge time
8hour(s)

Nominal Battery Voltage
12 V

Expected Battery Life (years)
1 - 2

Battery Volt-Amp-Hour Capacity
84

Communications & Management
Control panel
LED Status display with on line : on battery

Audible Alarm
Alarm when on battery : distinctive low battery alarm

Surge Protection and Filtering
Surge energy rating
273Joules

Physical
Maximum Height
138MM, 13.8CM

Maximum Width
98MM, 9.8CM

Maximum Depth
310MM, 31.0CM

Net Weight
4.2KG
