Overview
Lead time
Usually in Stock

Max. Capacity Used
100 %

Main Input Voltage
230 V

Main Output Voltage
230 V

rated power in W
300 W

rated power in VA
500 VA

Input Connection Type
IEC 60320 C14

nb of power socket outlets
3 IEC 60320 C13
1 IEC 60320 C13 surge
2 IEC Jumpers surge

number of cables
2

battery type
Lead-acid battery

max runtime
45 min

Number of power module free slots
0

Number of power module filled slots
0

redundant
No

mounting location
Front

mounting preference
No preference

mounting mode
Not rack-mountable

two post mountable
0

USB compatible
No

network frequency
47...63 Hz
50/60 Hz +/- 3 Hz auto-sensing

input voltage limits
160...300 V adjustable
180...266 V

maximum input current
7 A

switching current capacity
7 A

Maximum configurable power in W
300 W

output frequency
47...63 Hz sync to mains
50/60 Hz +/- 1 Hz unsynchronised

UPS type
Standby

Wave type
Stepped approximation to a sinewave

Maximum configurable power in VA
500 VA

Transfer time
6 ms typical : 10 ms maximum

Battery recharge time
8 h

number of battery replacement quantity
1

battery voltage
12 V

battery capacity
7.0 Ah

battery charger power
10 W rated

Battery power in VAH
83 VAh capacity
84 VAh runtime

control panel
LED status display with on line : on battery : replace battery and overload indicators

alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Surge Protection and Filtering
Surge energy rate
310 J

noise suppression
Full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449

Data line protection
RJ45 analog phone line for phone/fax/modem/DSL
