Main Input Voltage
230 V

rated power in W
900 W

rated power in VA
1600 VA

nb of power socket outlets
4 universal

cable length
1.22 m

number of cables
1

battery type
Lead-acid battery

General
provided equipment
User manual

max runtime
240 min

Number of power module free slots
0

Number of power module filled slots
0

redundant
No

Physical
colour
Black

height
19 cm

width
14 cm

depth
39 cm

net weight
10.3 kg

mounting preference
No preference

mounting mode
Not rack-mountable

two post mountable
0

USB compatible
No

Input
network frequency
50/60 Hz +/- 5 Hz auto-sensing

input voltage limits
140...300 V

Input Power Factor at Full Load
0.56

Output
Maximum configurable power in W
900 W

output frequency
50/60 Hz +/- 1 Hz sync to mains

UPS type
Line interactive

Waveform Type
Stepped approximation to a sinewave

full load runtime
00:01:00 900 W

half load runtime
00:06:30 450 W

Maximum configurable power in VA
1600 VA

Transfer time
6 ms typical : 10 ms maximum

equipment protection policy
Lifetime : 50000 euros

Environmental
ambient air temperature for operation
0…40 °C

relative humidity
0…95 % non-condensing

operating altitude
0...3000 m

ambient air temperature for storage
-15…40 °C

storage Relative Humidity
0…95 % Non-condensing

storage altitude
0…3000 m

acoustic level
40 dBA

IP degree of protection
IP20

Batteries & Runtime
Run Time
View Runtime Graph

Efficiency
View Efficiency Graph

number of battery filled slots
0

number of battery free slots
0

Battery recharge time
8 h

battery voltage
24 V

Battery power in VAH
136 VAh runtime
168 VAh capacity

battery life
3…5 year(s)

Battery graph comments
Curve fit to measured runtime data. All measurements taken with new, fully charged batteries, at typical environmental conditions, with no electrical input and balanced resistive load (PF = 1.0) output.

extended runtime
0

Communications & Management
control panel
LED Status display with on line : on battery

alarm
Alarm when on battery : distinctive low battery alarm
Surge Protection and Filtering

Surge energy rate
273 J

Data line protection
RJ45 10/100/1000 Base-T Ethernet protection

Packing Units
Package 1 Weight
11.3 kg

Package 1 Height
29.7 cm

Package 1 width
23.5 cm

Package 1 Length
49.5 cm
