Output power capacity
600 Watts / 1.0kVA

Output Connections
(2) IEC Jumpers (Battery Backup)
(8) IEC 320 C13 (Battery Backup)

Nominal Output Voltage
230V

Nominal Input Voltage
230V

Input Connections
IEC 320 C14

Output
Max Configurable Power (Watts)
600 Watts / 1.0kVA

Output Voltage Distortion
Less than 5 % at full load

Output Frequency (sync to mains)
50/60 Hz +/- 3 Hz Sync to mains

Topology
Line interactive

Waveform type
Sine wave

Input
Input frequency
50/60 Hz +/- 3 Hz Auto-sensing

Input voltage range for main operations
170 - 300 Adjustable, 180 - 287V

Other Input Voltages
220 V, 240 V

Batteries & Runtime
Battery type
Lead-acid battery

Typical recharge time
3hour(s)

Replacement Battery
APCRBC142

Expected Battery Life (years)
3 - 5

RBC Quantity
1

Battery Charge Power (Watts)
56 Watts

Communications & Management
Interface Port(s)
USB

Control panel
Multifunction LCD status and control console

Audible Alarm
Alarm when on battery : distinctive low battery alarm : configurable delays

Surge Protection and Filtering
Surge energy rating
455Joules

Filtering
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449

Physical
Maximum Height
219MM, 21.9CM

Maximum Width
171MM, 17.1CM

Maximum Depth
439MM, 43.9CM

Net Weight
17.27KG

Shipping weight
19.55KG

Shipping Height
376MM, 37.6CM

Shipping Width
328MM, 32.8CM

Shipping Depth
595MM, 59.5CM
