UNPRECEDENTED MODULARITY
slide-in/ interlocking mechanism
PIN-to-PIN contact point for receiving power and signal
Reduced need for mounting screws

DESIGNATED CABLE MODULES FOR UNI FAN
Each UNI FAN features a cable module with a PIN-to-PIN contact point to receive power and signal. Each cable module can support up to 4 UNI FAN, allowing users to choose to use either a single fan or up to 4 fans in one go.

SOPHISTICATED RGB LIGHTING
The 32 addressable RGB LEDs embedded in each fan (16 LEDs on either side of the frame) ensure vibrant lighting effects.

VIBRANT RGB LIGHTING VISIBLE FROM ALL ANGLES
The 16 LEDs on each side shine through a diffuser, ensuring a smooth light is visible from all angles.

MORE DURABLE, EXTREMELY SILENT
A close look at what makes UNI FAN operate efficiently.

OPTIONAL KIT – ARGB DEVICE CABLE KITS
Supports all Lian Li product control by UNI HUB or connect UNI FAN directly to motherboard.

UPDATED SCREW HOLES OF UNI FAN SL SERIES
In order to minimize the tolerance interference with the radiator and case screw hole.

FAN DIMENSION
140 X 140 X25 ( mm )

RATED VOLTAGE
DC 12V(FAN) & 5V(LED)

FAN SPEED
500~1500RPM

MAX. AIR PRESSURE
1.67mmH2O

MAX. AIR FLOW
70.5 CFM

ACOUSTICAL NOISE (MIN-MAX.)
30dB(A) Max

LOCKED CURRENT
>= 10mA

BEARING TYPE
Fluid Dynamic Bearing(FDB)

START-UP VOLTAGE
DC 6.0V

INPUT CURRENT
100mA(FAN) / 340mA (LED)

INPUT POWER
3.6W
