Performance Specifications
# of Cores - 2
# of Threads - 2
Processor Base Frequency - 3.30 GHz
Cache - 3 MB Intel® Smart Cache
Bus Speed - 8 GT/s
TDP - 54 W

Supplemental Information
Embedded Options Available - Yes

Memory Specifications
Max Memory Size (dependent on memory type) - 64 GB
Memory Types - DDR4-1866/2133, DDR3L-1333/1600 @ 1.35V
Max # of Memory Channels - 2
Max Memory Bandwidth - 34.1 GB/s
ECC Memory Supported ‡ - Yes

Processor Graphics
Processor Graphics ‡ - Intel® HD Graphics 510
Graphics Base Frequency - 350 MHz
Graphics Max Dynamic Frequency - 1.00 GHz
Graphics Video Max Memory - 64 GB
Graphics Output - eDP/DP/HDMI/DVI
4K Support - Yes, at 60Hz
Max Resolution (HDMI 1.4)‡ - 4096x2304@24Hz
Max Resolution (DP)‡ - 4096x2304@60Hz
Max Resolution (eDP - Integrated Flat Panel)‡ - 4096x2304@60Hz
Max Resolution (VGA)‡ - N/A
DirectX* Support - 12
OpenGL* Support - 4.4
Intel® Quick Sync Video - Yes
Intel® InTru™ 3D Technology - Yes
Intel® Clear Video HD Technology - Yes
Intel® Clear Video Technology - Yes
# of Displays Supported ‡ - 3
Device ID - 0x1902

Expansion Options
Scalability - 1S Only
PCI Express Revision - 3.0
PCI Express Configurations ‡ - Up to 1x16, 2x8, 1x8+2x4
Max # of PCI Express Lanes - 16

Package Specifications
Sockets Supported - FCLGA1151
Max CPU Configuration - 1
Thermal Solution Specification - PCG 2015C (65W)
Package Size - 37.5mm x 37.5mm

Advanced Technologies
Intel® Optane™ Memory Supported ‡ - No
Intel® Turbo Boost Technology ‡ - No
Intel vPro® Platform Eligibility ‡ - No
Intel® Hyper-Threading Technology ‡ - No
Intel® Virtualization Technology (VT-x) ‡ - Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ - Yes
Intel® VT-x with Extended Page Tables (EPT) ‡ - Yes
Intel® Transactional Synchronization Extensions - No
Intel® 64 ‡ - Yes
Instruction Set - 64-bit
Instruction Set Extensions - Intel® SSE4.1, Intel® SSE4.2
Idle States - Yes
Enhanced Intel SpeedStep® Technology - Yes
Thermal Monitoring Technologies - Yes
Intel® Identity Protection Technology ‡ - Yes
Intel® Stable Image Platform Program (SIPP) - No

Security & Reliability
Intel® AES New Instructions - Yes
Secure Key - Yes
Intel® Software Guard Extensions (Intel® SGX) - Yes with Intel® ME
Intel® Memory Protection Extensions (Intel® MPX) - No
Intel® OS Guard - No
Intel® Trusted Execution Technology ‡ - No
Execute Disable Bit ‡ - Yes
Intel® Boot Guard - Yes
