General
Rip-Cord
Yes

Category
Cat.6

Sheath Printing
HIKVISION 4PR 23AWG 75°C U/UTP CAT6 VERIFIED TO ANSI/TIA-568-C.2 PVC ****m mm/dd/yyyy Tracing Code-HS

Reference Standard
ISO/IEC11801, ANSI/TIA-568-C.2, RoHS 2.0

Fire Resistance
No

Separator
Yes

Conductor
Material
Solid-Bare Copper (99.95%)

Diameter
0.55 ± 0.005 mm, 23 AWG

Insulation
Material

HDPE
Diameter
0.98 ± 0.05 mm

Sheath Physical Properties
Before Aging
Tensile strength ≥ 13.5 Mpa
Elongation ≥ 150%

Aging Period
100°C × 24h × 10d

After Aging
Tensile strength ≥ 12.5 Mpa
Elongation ≥ 125%

Cold Bend
-20 ± 2°C × 4h, 8 × cable O.D, no visible cracks

Electrical Characteristics(20℃)
1.0-250.0 MHz Impedance
100 ± 15 Ω @ ≤ 100 MHz
100 ± 25 Ω @100-250 MHz
1.0-250.0 Mhz Delay Skew
≤ 45 ns/100 m

DC Resistance
≤ 9.38 Ω/100 m

DC Conductor Resistance Unbalance
≤ 5.0%

Package Dimension
400 mm (W) × 400 mm (H) × 240 mm (D) (15.75" × 15.75" × 9.45")
12.3 ± 0.5kg

Cable Length
(305 ± 1.5) m

Ambient Temperature
-20°C to 75°C (-4°F to 167°F)

Operating Voltage
60 V

Sheath
Thickness
0.50 ± 0.10 mm

Material
PVC

Color
Orange

Diameter
6.00 ± 0.30 mm
