Banish WiFi Dead Zone— Mesh WiFi system with unique antenna placement delivers strong WiFi to every corner of your home, providing total wireless speed of 1800Mbps.

Hassle Free Control – 3 steps setup and easy management with ASUS Router App

Always Up-to-date Protectio — The lifetime free cloud-based security powered by Trend Micro makes sure your privacy on connected devices is protected.

Parental Controls — URL filter and scheduling allow you to protect your family from inappropriate content and unhealthy Internet usage behavior.

AiMesh Supported– Mix and match ZenWiFi with AiMesh-compatible routers to form powerful and flexible whole-home WiFi system

Specifications
Antenna - Internal dual-band antenna x 2
Transmit/Receive - MIMO technology / 2.4 GHz 2 x 2 / 5 GHz 2 x 2
Memory - 256 MB Flash, 256 MB RAM
Boosts speed - MIMO technology
Operating Frequency - 2.4 G Hz / 5 GHz
Ports - RJ45 for Gigabits BaseT for WAN/LAN x 1, RJ45 for Gigabits BaseT for LAN x1
Button - WPS Button, Reset Button
LED Indicator - Power x 1
Power Supply - AC Input : 110V~240V(50~60Hz) / DC Output : 12 V with max. 1.5 A current
Product Weight (g) - 295 g

AiMesh -
AiMesh : Yes
Primary AiMesh router : Yes
AiMesh node : Yes

Router APP - Yes
Game - Game Boost/acceleration : No
WTFast : No

Alexa - Support Alexa skill : Yes

AiProtection -
AiProtection : AiProtection Classic
Router Security Assessment : No
Malicious site blocking : Yes
Two-Way IPS : No
Infected Device Prevention and Blocking : Yes

Parental Control -
Parental Control : Yes
Parental Control Customized Internet schedule : Yes

Traffic Control -
Adaptive QoS : No
Bandwidth Monitor : Yes
Bandwidth limiter : Yes
Traditional QoS : Yes
Maximum Traditional QoS rule : 32
Traffic Monitor : No
Real-time traffic monitor : Yes
Wired Traffic Monitor : Yes
Wireless Traffic Monitor : Yes
Traffic Analyzer : No
Website history : Yes

Wireless
IPv6 : Yes
MU-MIMO : Yes
Wi-Fi Encryption : WPA3-Personal, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise, WPS support
Wi-Fi Encryption : WPA3-Personal, WPA/WPA2-Personal, WPA/WPA2-Enterprise, WPS support
UTF-8 SSID : Yes
Guest Network : Yes
Maximum Guest Network rule : 9
Guest Network Connection time limit : Yes
WPS : Yes
Wi-Fi MAC address filter : No
Wireless scheduler : No
Airtime fairness : No
RADIUS Server : No
Universal beamforming : No
Explicit beamforming : No

WAN
Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP
Dual WAN : No
WAN Aggregation : No
3G/4G LTE dongle : No
Android tethering : Yes
Port forwarding : Yes
Port triggering : Yes
DMZ : Yes
DDNS : Yes
NAT Passthrough : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP
Let’s Encrypt : Yes

LAN
DHCP Server : Yes
IGMP snooping : Yes
IPTV : Yes
LAN Link Aggregation : No
Manually assign IP address : Yes
Maximum manually assign IP address rule : 64

VPN
VPN Client L2PT : Yes
VPN Client OVPN : Yes
VPN Client PPTP : Yes
VPN Server IPSec : Yes
VPN Server OVPN : Yes
VPN Server PPTP : Yes
VPN Fusion : No

USB application HDD
hibernation : No
Safely Remove disk : No
AiCloud : No
Download master : No
AiDisk : No
Media Server : No
Time Machine : No
Samba Server : No
FTP Server : No
Shared Folder privileges : No

Administration
Operating system : ASUSWRT
Free OS upgrade : Yes
Firewall : Yes
Maximum Firewall keyword filter : 64
Maximum Firewall network service filter : 32
Maximum Firewall URL filter : 64
Wake on LAN (WOL) : Yes
SSH : Yes
Configuration backup and restore : Yes
Diagnosis tools : Yes
Feedback system : Yes
System log : Yes

Product Dimensions with antennas (L*W*H) mm 90 x 90 x 80 mm
