Main Input Voltage
230 V

rated power in W
480 W

rated power in VA
950 VA

output connection type
2 IEC 60320 C13
4 universal receptacle

cable length
1.22 m

number of cables
2

battery type
Lead-acid battery

product web sub-family
Entry level

Number of power module free slots
0

Number of power module filled slots
0

redundant
No

Physical
colour

Black
height
21.5 cm

width
13 cm

depth
33.6 cm

net weight
8 kg

mounting preference
No preference

mounting mode
Not rack-mountable

two post mountable
0

USB compatible
Yes

Input
network frequency
50/60 Hz +/- 3 Hz auto-sensing

input voltage limits
150...280 V

maximum input current
4 A

switching current capacity
7 A

input protection type
3-pole circuit breaker

input current
4 A (1 phase)

Output
Maximum configurable power in W
480 W

output frequency
50/60 Hz +/- 1 Hz sync to mains
50/60 Hz +/- 1 Hz unsynchronised

UPS type
Line interactive

Wave type
Stepped approximation to a sinewave

Maximum configurable power in VA
950 VA

Transfer time
8 ms typical : 10 ms maximum

Environmental
ambient air temperature for operation
0…40 °C

relative humidity
0…95 % non-condensing

operating altitude
0...10000 ft

ambient air temperature for storage
-15…45 °C

storage Relative Humidity
Non-condensing 0…95 %

storage altitude
0.00…9144.00 m

acoustic level
45 dBA

number of battery filled slots
1

number of battery free slots
0

Battery recharge time
8 h

battery charger power
9 W rated

Battery power in VAH
108 VAh capacity
76 VAh runtime

Communications & Management
control panel
LED status display with on line : on battery : replace battery and overload indicators

alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Surge Protection and Filtering

Surge energy rate
273 J

Data line protection
RJ11 modem/fax protection

Packing Units
Unit Type of Package 1
PCE

Package 1 Length
24.5 cm

Number of Units in Package 1
1

Package 1 Width
44 cm

Package 1 Height
29.5 cm

Package 1 Weight
8.99 kg
