Main Input Voltage
230 V AC 1 phase

Main Output Voltage
230 V AC 1 phase

Rated power in W
480 W

Rated power in VA
900 VA

Input Connection Type
IEC 60320 C14

output connection type
2 universal
1 IEC 60320 C13

Cable length
1.22 m

number of cables
1

Battery type
Lead-acid battery

Max runtime
120 min

Number of power module free slots
0

Number of power module filled slots
0

Redundant
No

UPS size
WS

Height
16 cm

Width
12 cm

Depth
35.5 cm

Product weight
6 kg

Mounting support
Floor

Mounting preference
No preference

Mounting mode
Not rack-mountable

Two post mountable
0

USB compatible
No

network frequency
50/60 Hz +/- 5 Hz auto-sensing

input voltage limits
140...300 V 230 V AC

Cos phi
0.53

Maximum configurable power in W
480 W

output frequency
50/60 Hz +/- 1 Hz sync to mains

UPS type
Line interactive

Wave type
Stepped approximation to a sinewave

full load runtime
00:01:00 480 W

Graph display
1

half load runtime
00:06:30 240 W

Maximum configurable power in VA
900 VA

Transfer time
6 ms typical : 10 ms maximum

Number of battery filled slots
0

Number of battery free slots
0

Battery recharge time
8 h

Battery voltage
12 V

Battery capacity
9.0 Ah

Surge energy rate
273 J

Package 1 Height
25 cm

Package 1 Width
43 cm

Package 1 Length
19.7 cm

Package 1 Weight
6.5 kg
