Zero Cable Platform
Farewell to messy cables! We have connected the back panel and the PCB with a copper plate for better heat dissipation and impressive output power quality.

Smart Zero Fan
Designed with our Smart Zero Fan, the fan will not spin until the load exceeds 30% of the power supply, minimizing the fan noise.

＜30mV Low Ripple Noise
All ripples are lower than 30mV on +12V, +5V or +3.3V from 0% to 100% load to ensure a stable operation and keep your performance-critical components to function reliably for longer.

Extremely Strict Voltage Regulation ＜±2%
The voltage regulation, more strict than Intel’s standard ±5% for major rails and ±10% for -12V, is set to no more than ±2% for major rails to meet the highest performance.

Fully Modular Low-Profile Flat Cable
Offers cable selection for users while powering the system at an advantageous voltage. Low-profile flat black cable makes cable management easier, reduces clutter and increases airflow inside the chassis.

Premium Japanese 105°C/221°F Capacitors
Providing great durability as well as offering the highest stability, while remaining reliable.

High Amperage Single +12V Rail
Powerful single +12V rail ensures a stable and reliable supply to other PC components.

WATTS - 1000W
FORM FACTOR - ATX
MAX. OUTPUT CAPACITY - 1000W
PEAK OUTPUT CAPACITY - 1200W
COLOR - Black
DIMENSION ( W / H / D ) - 150mm(W) x 86mm(H) x 160mm(D)
WEIGHT - 1.8kg
PFC (POWER FACTOR CORRECTION) - Active PFC
POWER GOOD SIGNAL - 100-500 msec
HOLD UP TIME - > 16msec at 100% of full load
INPUT CURRENT - 15A max
INPUT FREQUENCY RANGE - 50Hz /60Hz
INPUT VOLTAGE - 100V – 240V~
OPERATING TEMPERATURE - 0°C to + 50°C
OPERATING HUMIDITY - 20% to 90%,non-condensing
STORAGE TEMPERATURE - -20°C to + 70°C
STORAGE HUMIDITY - 5% to 95%, non-condensing
COOLING SYSTEM - 14cm hydraulic bearing fan
EFFICIENCY - Meet 80 PLUS®Gold at 115Vac input.
MTBF - 100,000 hrs minimum
SAFETY APPROVAL - CE/cTUVus/TÜV/FCC/BSMI/EAC
PCI-E 6+2PIN - 6
PROTECTION - OCP, OVP, OPP, SCP, OTP
