Built-in SIM card slot
4G LTE / 3G with up to 150 Mbps download
Fail-safe Internet with fixed-line and mobile Internet support
Wireless AC1200 (866 Mbps on 5 GHz + 300 Mbps on 2.4 GHz)
Gigabit WAN/LAN + 3 x Gigabit Ethernet LAN

Features
Connectivity
Share your 3G/4G connection with multiple devices
Uses a SIM/UICC card to connect to the Internet
One Gigabit WAN port to connect to broadband Internet
Four Gigabit Ethernet LAN ports to connect wired devices
Fast Wireless 802.11ac/n/g/b/a
Easy-to-use web GUI

Security Features
Industry-standard WPA/WPA2 encryption
Network Address Translation (NAT) firewall
Stateful Packet Inspection (SPI) firewall

General
Frequency Support
LTE Bands:
Release 10, Cat 4: Bands 1/2/3/5/7/8/20/38/40
(FDD: 2100/1900/1800/850/2600/900/800 MHz,
TDD: 2600/TDD 2300 MHz)
Pentaband UMTS/HSPA/HSPA+/DC-HSPA+
1/2/3/5/8 (2100/1900/1800/850/900 MHz)
Quadband GSM/GPRS/EDGE
850/900/1800/1900 MHz

Device Interfaces
One 10/100/1000 Gigabit Ethernet WAN port
Four 10/100/1000 Gigabit Ethernet LAN ports
Two detachable 4G LTE antennas

Data Rates
LTE Downlink: Up to 150 Mbps
LTE Uplink: Up to 50 Mbps1
DC-HSPA Downlink: Up to 42 Mbps
DC-HSPA Uplink: Up to 5.72 Mbps

Standards
802.11ac/n/g/b/a
802.3i
802.3u

Wi-Fi Data Rates
Up to 866 Mbps with 802.11ac clients
Up to 300 Mbps with 802.11n clients
6/9/11/12/18/24/36/48/54 Mbps in 802.11g mode
1/2/5.5/11 Mbps in 802.11b mode

Functionality
Wireless Encryption
64/128-bit WEP (Wired Equivalent Privacy)
WPA & WPA2 (Wi-Fi Protected Access)

Firewall
Network Address Translation (NAT)
Stateful Packet Inspection (SPI)

Advanced Features
L2TP/PPTP/IPSec VPN Passthrough
User configurable multi-WAN
DMZ (Demilitarized Zone)
Port/Application Forwarding
URL Filter
QoS engine (Quality of Service)
Scheduler
Virtual server

Physical
LED Status Indicators
Power
Internet
5 GHz
2.4 GHz
4G
2G/3G
LAN
WAN
SMS
Signal Strength

Dimensions
170 x 180 x 80 mm (6.69 x 7.09 x 3.15 in)

Weight
400 g (14.1 oz)
